Home Brands Baumer Industrial Camera VCXU-125M.R Baumer VCXU-125M.R Industrial Camera The Baumer VCXU-125M.R Industrial Camera offers a 69.4 dB dynamic range, Rolling shutter, Global reset shutter , C-mount , and Sony IMX226 connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.
Brand Baumer Product Type Industrial Camera Model Number VCXU-125M.R
Baumer VCXU-125M.R Industrial Camera – Technical Specifications Specification Value Sensor Sony IMX226 Mono/Color Mono Sensor type 1/1.7″ CMOS Shutter type Rolling shutter, Global reset shutter Resolution 4000 × 3000 px Pixel size 1.85 × 1.85 µm Exposure time 0.044 … 60000 ms Dark noise 3.08 e- Saturation capacity 10993 e- Dynamic range 69.4 dB Signal-to-noise ratio 40.4 dB Image formats, interface frame rate max. Full Frame, 4000 × 3000 px, max. 29 fps, Binning 2×2, 2000 × 1500 px, max. 31 fps, Binning 2×1, 2000 × 3000 px, max. 29 fps, Binning 1×2, 4000 × 1500 px, max. 31 fps Image formats, aquisition frame rate max. (Burst Mode) Full Frame, 4000 × 3000 px, max. 31 fps Pixel formats Mono8, Mono10, Mono12, Mono12 Packed Analog controls Gain (0 … 20 dB), Offset (0 … 255 LSB 12 Bit) Color models Mono Internal image buffer 481 MB, 14 images (Trigger Mode), 1 image (Free Running Mode) Process interface M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) Power supply via USB 3.0 interface Lens mount C-mount Width 29 mm Height 29 mm Depth 38 mm Weight ≤ 90 g Material zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 Power consumption Approx. 3.3 W @ 29 fps Flash memory size 128 kB Operating temperature 0 … +65 ° @ T = measurement point Storage temperature -20 … +70 °C Humidity 10 … 90 % (non-condensing) Protection class IP 40 (with mounted lens and cable)
