Baumer VCXG-127C Industrial Camera
The Baumer VCXG-127C Industrial Camera offers a 69.5 dB dynamic range, Global shutter, C-mount, and Sony IMX545 Gen4 connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.
| Brand | Baumer |
| Product Type | Industrial Camera |
| Model Number | VCXG-127C |
Baumer VCXG-127C Industrial Camera β Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Sony IMX545 Gen4 |
| Mono/Color | Color |
| Sensor type | 1/1.1" CMOS |
| Shutter type | Global shutter |
| Resolution | 4096 Γ 2992 px |
| Pixel size | 2.74 Γ 2.74 Β΅m |
| Exposure time | 0.001 β¦ 60000 ms |
| Dark noise | 2.29 e- |
| Saturation capacity | 8794 e- |
| Dynamic range | 69.5 dB |
| Signal-to-noise ratio | 39.4 dB |
| Image formats, interface frame rate max. | Full Frame, 4096 Γ 2992 px, max. 10 fps, Binning 2Γ2, 2048 Γ 1496 px, max. 11 fps, Binning 2Γ1, 2048 Γ 2992 px, max. 11 fps, Binning 1Γ2, 4096 Γ 1496 px, max. 11 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 4096 Γ 2992 px, max. 11 fps |
| Pixel formats | BayerRG8, BayerRG10, BayerRG12, BayerRG12 Packed, Mono8, Mono10, Mono12, Mono12 Packed, RGB8, BGR8 |
| Analog controls | Gain (0 β¦ 48 dB), Offset (0 β¦ 255 LSB 12 Bit) |
| Color models | Mono, Raw Bayer, RGB, BGR |
| Color processing | Integrated color processor for high quality color calculation |
| Internal image buffer | 141 MB, 4 image (Trigger Mode), 1 image (Free Running Mode) |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via M8/8 pins or Power over Ethernet (PoE) |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 49 mm |
| Weight | β€ 120 g |
| Material | zinc die casting, baked varnish |
| Voltage supply range +Vs | 12 β¦ 24 V DC (external power supply), 36 β¦ 57 V DC (Power over Ethernet) |
| Power consumption | Approx. 2.5 W @ 12 VDC and 10 fps, Approx. 3.2 W @ 48 VDC (PoE) and 10 fps |
| Flash memory size | 128 kB |
| Operating temperature | 0 β¦ +65 Β° @ T = measurement point |
| Storage temperature | -20 β¦ +70 Β°C |
| Humidity | 10 β¦ 90 % (non-condensing) |
| Protection class | IP 40 (with mounted lens and cable) |
