Baumer VCXG-124C.I Industrial Camera

Name: Baumer VCXG-124C.I 11186794
Brand: Baumer
SKU: VCXG-124C.I
Rating: 4.8 (19 reviews)

The Baumer VCXG-124C.I Industrial Camera offers a 70.6 dB dynamic range, Global shutter, C-mount, and Sony IMX304 Gen2 connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.

Datasheet

Brand	Baumer
Product Type	Industrial Camera
Model Number	VCXG-124C.I

Baumer VCXG-124C.I Industrial Camera – Technical Specifications

Specification	Value
Sensor	Sony IMX304 Gen2
Mono/Color	Color
Sensor type	1.1″ CMOS
Shutter type	Global shutter
Resolution	4096 × 3000 px
Pixel size	3.45 × 3.45 µm
Exposure time	0.001 … 60000 ms
Dark noise	2.09 e-
Saturation capacity	9338 e-
Dynamic range	70.6 dB
Signal-to-noise ratio	39.7 dB
Quantum efficiency	46 % @ 465 nm, 56.3 % @ 536 nm, 52.1 % @ 631 nm
Image formats, interface frame rate max.	Full Frame, 4096 × 3000 px, max. 9 fps, Binning 2×2, 2048 × 1500 px, max. 15 fps, Binning 2×1, 2048 × 3000 px, max. 15 fps, Binning 1×2, 4096 × 1500 px, max. 15 fps
Image formats, aquisition frame rate max. (Burst Mode)	Full Frame, 4096 × 3000 px, max. 15 fps
Pixel formats	BayerRG8, BayerRG10, BayerRG12, BayerRG12 Packed, Mono8, Mono10, Mono12, Mono12 Packed, RGB8, BGR8
Analog controls	Gain (0 … 48 dB), Offset (0 … 255 LSB 12 Bit)
Color models	Mono, Raw Bayer, RGB, BGR
Basic Functions	Exposure, Gain / Color Gain, Trigger / Exposure Active (Flash), Binning 2x2, Partial Scan, Offset, Free Running Mode (Live Image)
Auto Functions	Exposure Auto, Gain Auto, White Balance Auto, Color Transformation Auto
Image Pre-processing	Image Flipping (X/Y), Color Processing (RGB, BGR, Mono), Color Enhancement (with optimized ColorTransformationMatrix), LUT / Gamma
Acquisition / Interface	Burst Mode, Adjustable Framerate, Short Exposure Time Enable, Device Link Throughput Limit, Internal Image Buffer
Synchronization	free running, trigger
Trigger sources	Hardware, Software, ActionCommand
Trigger delay	0 … 2 sec, tracking and buffering of up to 128 trigger signals
Process Synchronization	Events, Timer, Trigger Delay, Debouncer, Counter, Sequencer, Trigger via Action CMD (GigE), Additional Output Modes (e.g. Trigger Ready), PWM (PWM Duration / PWM Duty Cycle), 4 power outputs with up to 120 W (max. 48 V / 2.5 A), Selectable Output format (e.g. Tri State, Push Pull), Chunk data inside transferred image, Encoder support via Counter End trigger source
Additional Functions	User Set, Integrated temperature sensor, Readable additional information (e.g. sensor information)
Internal image buffer	36 MB, 1 image (Trigger Mode), 1 image (Free Running Mode)
Data interface	Gigabit Ethernet, Transfer rate 1000 Mbits/sec, Fast Ethernet, Transfer rate 100 Mbits/sec, Connector: M12 / 8 pol x-coded, screwable type
Process interface	M12 / 12 pins a-coded (SACC-CI-M12MS-12CON-L180)
Power supply	via M12/12 pins a-coded or Power over Ethernet (PoE)
Lens mount	C-mount
Width	40 mm
Height	40 mm
Depth	50.8 mm
Weight	≤ 137 g
Material	aluminum, hard-anodized
Voltage supply range +Vs	12 … 24 V DC (external power supply), 36 … 57 V DC (Power over Ethernet)
Power consumption	Approx. 2.6 W @ 12 VDC and 9 fps, Approx. 3.2 W @ 48 VDC (PoE) and 9 fps
Flash memory size	128 kB
Operating temperature	0 … +65 ° @ T = measurement point
Storage temperature	-20 … +70 °C
Humidity	10 … 90 % (non-condensing)
Protection class	IP 40 (with mounted lens and cable), IP 54 (with mounted lens and cable), IP 65 (with mounted tube and cable), IP 67 (with mounted tube and cable), IP 69K (with stainless steel housing accessory)
Lines	4 input lines, 4 power output lines with pulse width modulation (PWM) (max. 48 V / max. 2,5 A)
