Baumer VCXG-03SWIR.XC Industrial Camera
The Baumer VCXG-03SWIR.XC Industrial Camera offers a 57 dB dynamic range, Global shutter, C-mount, and Sony IMX991 connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.
| Brand | Baumer |
| Product Type | Industrial Camera |
| Model Number | VCXG-03SWIR.XC |
Baumer VCXG-03SWIR.XC Industrial Camera – Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Sony IMX991 |
| Mono/Color | SWIR |
| Sensor type | 1/4″ CMOS |
| Shutter type | Global shutter |
| Resolution | 656 × 520 px |
| Pixel size | 5 × 5 µm |
| Exposure time | 0.001 … 60000 ms |
| Dark noise | 260 e- |
| Saturation capacity | 180000 e- |
| Dynamic range | 57 dB |
| Signal-to-noise ratio | 52.6 dB |
| Quantum efficiency | 69 % @ 536 nm, 66 % @ 631 nm |
| Image formats, interface frame rate max. | Full Frame, 656 × 520 px, max. 237 fps, Binning 2×2, 328 × 260 px, max. 237 fps, Binning 2×1, 328 × 520 px, max. 237 fps, Binning 1×2, 656 × 260 px, max. 237 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 656 × 520 px, max. 237 fps |
| Pixel formats | Mono8, Mono10, Mono12, Mono12 Packed |
| Analog controls | Gain (0 … 48 dB), Offset (0 … 255 LSB 12 Bit) |
| Color models | Mono |
| Basic Functions | Exposure, Gain, Trigger / Exposure Active (Flash), Binning 2x2, Partial Scan, Offset, Free Running Mode (Live Image) |
| Auto Functions | Exposure Auto, Gain Auto |
| Image Pre-processing | Image Flipping (X/Y), LUT / Gamma, Defect Pixel Correction (static/list, dynamic/threshold) |
| Acquisition / Interface | Burst Mode, Adjustable Framerate, Short Exposure Time Enable, Device Link Throughput Limit, Internal Image Buffer |
| Synchronization | free running, trigger |
| Trigger sources | Hardware, Software, ActionCommand |
| Trigger delay | 0 … 2 s, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | Events, Timer, Trigger Delay, Debouncer, Counter, Sequencer, Trigger via Action CMD (GigE), Additional Output Modes (e.g. Trigger Ready), Chunk data inside transferred image, Encoder support via Counter End trigger source |
| Additional Functions | User Set, Integrated temperature sensor (InHouse and Sensor), Readable additional information (e.g. sensor information) |
| Data interface | Gigabit Ethernet, Transfer rate 1000 Mbits/sec, Fast Ethernet, Transfer Rate 100 Mbits/sec, Connector: 8P8C Modular Jack (RJ45), screwable TYPE090 (according to GigE Vision Mechanical Supplement) |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via M8 / 8 pins |
| Lens mount | C-mount |
| Width | 36 mm |
| Height | 36 mm |
| Depth | 46.1 mm |
| Weight | ≤ 110 g |
| Material | aluminum, baked varnish |
| Voltage supply range +Vs | 12 … 24 V DC (external power supply) |
| Power consumption | Approx. 2.1 W @ 12 VDC and 237 fps |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 ° @ T = measurement point |
| Storage temperature | -20 … +70 °C |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 (with mounted lens and cable) |
| Lines | 1 input line, 1 output line, 2 general purpose lines |
| Output line sources | Off, Exposure Active, Timer1, Readout Active, UserOutput 1-3, TriggerReady |
