Baumer UZAM 30N6103/S14 Ultrasonic Sensor
The Baumer UZAM 30N6103/S14 Ultrasonic Sensor offers a Cylindrical threaded design, 100 β¦ 1000 mm range, 12 β¦ 30 VDCV supply voltage, NPN make function (NO) output, and Connector M12 connection. Manufactured by Baumer under the Baumer Ultrasonic Sensor category, this model belongs to the UZAM Series.
| Brand | Baumer |
| Product Type | Ultrasonic Sensor |
| Model Number | UZAM 30N6103/S14 |
Baumer UZAM 30N6103/S14 Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Scanning range Sd | 100 β¦ 1000 mm |
| Scanning range far limit Sde | 100 β¦ 1000 mm |
| Version | Standard |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 2 % Sde |
| Sonic frequency | 240 kHz |
| Adjustment | Teach-in |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Output circuit | NPN make function (NO) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Width / diameter | 30 mm |
| Height / length | 70 mm |
| Connection types | Connector M12 |
| Operating temperature | -10 β¦ +60 Β°C |
| Protection class | IP 67 |
| Output indicator | Green / yellow LED |
Talk to Our Engineer for Baumer NPN Function Ultrasonic Sensor UZAM 30N6103/S14 part no: 10131012 with exclusive offers. Core System Specifications of UZAM 30N6103/S14, 10131012 are scanning range of 100 β¦ 1000 mm. This Standard sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 240 kHz. It features Teach-in, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 β¦ 30 VDC and uses a NPN make function (NO) output circuit, supporting an output current of up to 200 mA. Designed in compact Cylindrical threaded housing, it measures 30 mm in width and 70 mm in height, making it suitable for various industrial applications. The housing is made from durable Brass nickel plated, ensuring longevity in demanding environments. The sensor connects via an Connector M12, offering easy integration into your system. Don't Miss Out on a Quote for your requirement of Baumer NPN Function Ultrasonic Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
