Baumer URAM 12N8910/S14O Photoelectric Sensor
The Baumer URAM 12N8910/S14O Photoelectric Sensor offers a Cylindrical threaded design, 0 β¦ 70 mm scanning range, Β± 2,5 % Sde, NPN make function (NO) / break function (NC) output, and Connector M12 connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the retro-reflective type.
| Scanning range Sd | 0 β¦ 70 mm |
| Output circuit | NPN make function (NO) / break function (NC) |
| Connection types | Connector M12 |
Baumer URAM 12N8910/S14O Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Scanning range Sd | 0 β¦ 70 mm |
| Reflector position Sde | 40 β¦ 70 mm |
| Adjusting range reflector (operating range) | Β± 2,5 % Sde |
| Adjusting range reflector (limit range) | Β± 5 % Sde |
| Repeat accuracy | 1.5 mm |
| Temperature drift | < 2 % Sde |
| Sonic frequency | 380 kHz |
| Adjustment | External Teach-in |
| Alignment aid | Target indication flashing |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Output circuit | NPN make function (NO) / break function (NC) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Design | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Width / diameter | 12 mm |
| Height / length | 70 mm |
| Connection types | Connector M12 |
| Operating temperature | -10 β¦ +60 Β°C |
| Protection class | IP 67 |
Please speak to our Technical Engineer for Baumer High Speed Retro-reflective Sensor URAM 12N8910/S14O part no: 11053885 at attractive prices. Technical Specs Summary of URAM 12N8910/S14O, 11053885 includes scanning range of 0 β¦ 70 mm and sonic frequency of 380 kHz, featuring adjustable settings via External Teach-in. The sensor is equipped with a light indicator and for power on indication. Voltage supply ranges from 12 β¦ 30 VDC with a typical current consumption of . It operates with a NPN make function (NO) / break function (NC) output circuit and supports up to 200 mA output current, with a voltage drop (Vd) of less than <2 VDC. The Cylindrical threaded housing is made of durable Brass nickel plated, with dimensions of 12 mm in width and 70 mm in height, and an Connector M12. Match Your Needs with a Quote for your requirement of Baumer High Speed Retro-reflective Sensor. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
