Home Products Level Sensor Baumer UR18.DA0.2-IAMJ.9SF Baumer UR18.DA0.2-IAMJ.9SF: Level Sensors Technical Specifications of Baumer UR18.DA0.2-IAMJ.9SF 11200640:
Voltage supply range +Vs 12 … 30 VDC Output circuit Current output Output current 100 mA
Baumer Level Sensors UR18.DA0.2-IAMJ.9SF Technical Specifications Specification Value Power on indication LED green Voltage supply range +Vs 12 … 30 VDC Output circuit Current output Output current 100 mA Voltage drop Vd <3.5 VDC Short circuit protection Yes Reverse polarity protection Yes, Vs to GND Design Cylindrical threaded Housing material Stainless steel (V2A) / TR90 Connection types Connector M12 5 pin Operating temperature -25 … +65 °C Storage temperature -40 … +75 °C Protection class IP 69 Scanning range Sd 20 … 1000 mm Scanning range close limit Sdc 20 … 1000 mm Scanning range far limit Sde 20 … 1000 mm Version IO-Link dual channel, Multiplex version Hysteresis typ. 4 % Sde Repeat accuracy 0.5 mm Resolution < 0.3 mm Temperature drift > 50 mm < 2 % of distance to target Sde Power-up drift Compensated after 15 min. Sonic frequency 200 kHz Adjustment qTeach, line-Teach, IO-Link Light indicator LED yellow Alignment measuring axis < 2° Current consumption typ. 35 mA Baud rate 38.4 kBaud (COM 2) Output signal 4 ... 20 mA / 20 ... 4 mA Residual ripple < 10 % Vs Interface IO-Link V1.1 Cycle time ≥ 12 ms Process data length 48 Bit Process data structure Bit 0 = SSC1 (distance), Bit 1 = SSC2 (distance), Bit 2 = quality, Bit 3 = alarm, Bit 5 = SSC4 (counter), Bit 8-15 = scale factor, Bit 16-47 = 32 Bit measurement IO-Link port type Class A Additional data Distance, Excess gain, Operating cycles, Operating hours, Boot cycles, Operating voltage, Device temperature, Histograms Adjustable parameters Switching point, Switching hysteresis, Measured value filtering, Time filters, LED status indicators, Output logic, Output circuit, Counter, Beam forming, Analog output characteristic, Function of pin 5, Deactivate the sensor element, Find Me function Width / diameter 18 mm Height / length 64 mm Response time ton < 40 ms Release time toff < 40 ms
