Baumer UNDK 30U6103 Ultrasonic Distance Sensor
The Baumer UNDK 30U6103 Ultrasonic Distance Sensor offers a Rectangular design, 100 ... 1000 mm scanning range, Voltage output output, and Cable, L=2 m connection. Manufactured by Baumer under the Baumer Ultrasonic Distance Sensor category, this model belongs to the UNDK Series.
| Brand | Baumer |
| Product Type | Ultrasonic Distance Sensor |
| Product | UNDK 30U6103 |
Baumer UNDK 30U6103 Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Scanning range Sd | 100 ... 1000 mm |
| Version | - |
| Hysteresis typ. | - |
| Repeat accuracy | 0.5 mm |
| Response time ton | < 80 ms |
| Release time toff | < 80 ms |
| Sonic frequency | 240 kHz |
| Adjustment | Teach-in |
| Light indicator | Yellow LED / red LED |
| Power on indication | - |
| Alignment measuring axis | - |
| Voltage supply range +Vs | 15 β¦ 30 VDC |
| Output circuit | Voltage output |
| Output current | 20 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | - |
| Baud rate | - |
| Cycle time | - |
| Process data length | - |
| IO-Link port type | - |
| IO-Link | - |
| Design | Rectangular |
| Housing material | Polyester / die-cast zinc |
| Width / diameter | 30 mm |
| Height / length | 65 mm |
| Depth | 31 mm |
| Connection types | Cable, L=2 m |
| Operating temperature | -10 β¦ +60 Β°C |
| Protection class | IP 67 |
Give Us a Call for Baumer 2m Cable Ultrasonic Distance Sensor UNDK 30U6103 part no: 10127059 with budget-friendly prices. Technical Attributes are UNDK 30U6103, 10127059 include sensor operates within a range of 100 ... 1000 mm, with an accuracy of 0.5 mm. It features a fast response time of < 80 ms and operates at a frequency of 240 kHz. The sensor supports Teach-in for easy setup and includes Yellow LED / red LED indicators for status monitoring. It operates on a 15 β¦ 30 VDC power supply and provides a Voltage output with a current consumption of 20 mA. The sensor is housed in a Rectangular body made of Polyester / die-cast zinc, measuring 30 mm in diameter and 65 mm in length. It includes an Cable, L=2 m and is rated IP 67, ensuring protection against dust and water. The sensor operates reliably in temperatures from -10 β¦ +60 Β°C. Navigate Your Needs with a Quote for your requirement of Baumer 2m Cable Ultrasonic Distance Sensor. We excel in offering more cost-effective and supportive solutions than other Competitors.
