Baumer UNAM 12P1914/S14 Ultrasonic Sensor
The Baumer UNAM 12P1914/S14 Ultrasonic Sensor offers Cylindrical threaded,design, 10 … 200 mm, range, 12 … 30 VDC supply voltage, PNP make function (NO)output, Connector M12 connection. Manufactured by Baumer under the Banner Ultrasonic Sensor category, this model belongs to the UNDK Series.
| Brand | Baumer |
| Product Type | Ultrasonic Sensor |
| Model Number | UNAM 12P1914/S14 |
Baumer UNAM 12P1914/S14 Ultrasonic Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Emitter / receiver | - |
| Scanning range Sd | 10 … 200 mm |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Response time ton | < 10 ms |
| Release time toff | < 10 ms |
| Sonic frequency | 380 kHz |
| Adjustment | External Teach-in |
| Output indicator | LED green |
| Voltage supply range +Vs | 12 … 30 VDC |
| Output circuit | PNP make function (NO) |
| Output current | 200 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Width / diameter | 12 mm |
| Height / length | 70 mm |
| Depth | - |
| Connection types | Connector M12 |
| Operating temperature | -10 … +60 °C |
| Protection class | IP 67 |
The UNAM 12P1914/S14: 10140060 by Baumer is a compact ultrasonic proximity sensor designed for high-resolution, close-range object detection with exceptional consistency. Operating on a 12–30 VDC supply, this sensor features a reliable PNP make function (NO) output capable of handling up to 200 mA. It functions within a precise scanning range of 10–200 mm and achieves repeat accuracy of 0.5 mm, making it suitable for small-part detection, edge positioning, and bottling applications where reliability and speed are essential.
Equipped with External Teach-in adjustment for flexible setup and calibration, the sensor provides a user-friendly configuration interface even in dynamic production environments. The integrated green LED indicator offers quick status verification during setup or operation. With a response time under 10 ms and a sonic frequency of 380 kHz, this model enables fast feedback in automated inspection and material handling systems. Its durable nickel-plated brass cylindrical housing (12 mm diameter × 70 mm length) is IP67 rated, ensuring full protection against dust ingress and water spray, making it suitable for use in wet or dusty manufacturing zones.
The Baumer UNAM 12P1914/S14 is a go-to sensor for industrial use cases requiring short-distance, non-contact detection with millimeter-level precision. It is especially useful in automated filling lines, cap or label presence checks, and miniature part detection on conveyors or robotic arms. The sensor’s ultrasonic nature allows it to detect transparent, reflective, or irregular objects—overcoming common challenges posed to optical sensors.
Engineers frequently deploy this sensor in packaging machinery, semiconductor fabrication, and automated assembly systems where reliable detection of parts under 200 mm is critical for maintaining quality and speed. Its External Teach-in function allows for easy recalibration during changeovers, making it extremely versatile in environments with frequently changing production formats.
For Indian maintenance engineers and engineering students, the UNAM 12P1914/S14 offers a practical, rugged, and easy-to-deploy solution for applications requiring fast detection in compact setups. Its compact form factor, IP67 protection, and rapid response make it a reliable fit for smart factories embracing Industry 4.0-level sensor integration.
