Baumer U500.DA0.2-IA1B.72F: Level Sensors
Technical Specifications of Baumer U500.DA0.2-IA1B.72F 11200630:
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Output circuit | Current output |
Baumer Level Sensors U500.DA0.2-IA1B.72F Technical Specifications
| Specification | Value |
|---|---|
| Power on indication | LED green |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Output circuit | Current output |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Depth | 32 mm |
| Connection types | Connector M12 5 pin |
| Operating temperature | -25 β¦ +65 Β°C |
| Storage temperature | -40 β¦ +75 Β°C |
| Protection class | IP 67 |
| Scanning range Sd | 20 β¦ 1000 mm |
| Scanning range close limit Sdc | 20 β¦ 1000 mm |
| Scanning range far limit Sde | 20 β¦ 1000 mm |
| Repeat accuracy | 0.5 mm |
| Resolution | < 0.3 mm |
| Temperature drift | > 50 mm < 2 % of distance to target Sde |
| Power-up drift | Compensated after 15 min. |
| Sonic frequency | 200 kHz |
| Adjustment | qTeach, line-Teach |
| Light indicator | LED yellow |
| Alignment measuring axis | < 2Β° |
| Current consumption typ. | 35 mA |
| Output signal | 4 ... 20 mA / 20 ... 4 mA |
| Residual ripple | < 10 % Vs |
| Width / diameter | 18 mm |
| Height / length | 45 mm |
| Response time ton | < 40 ms |
| Release time toff | < 40 ms |
