Baumer U300.P50-GP2J.72CU Ultrasonic Sensor
The Baumer U300.P50-GP2J.72CU Ultrasonic Sensor offers a Rectangular design, 15 β¦ 500 mm range, 12 β¦ 30 VDCV supply voltage, Push-pull output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Ultrasonic Sensor category, this model belongs to the U300 Series.
| Brand | Baumer |
| Product Type | Ultrasonic Sensor |
| Model Number | U300.P50-GP2J.72CU |
Baumer U300.P50-GP2J.72CU Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Scanning range Sd | 15 β¦ 500 mm |
| Scanning range far limit Sde | 15 β¦ 500 mm |
| Version | IO-Link dual channel, Multiplex version |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 2 % Sde |
| Power-up drift | Compensated after 15 min. |
| Response time ton/toff min | < 16 ms |
| Response time ton/toff standard | < 40 ms |
| Sonic frequency | 290 kHz |
| Adjustment | qTeach, line-Teach, IO-Link |
| Power on indication | LED green |
| Alignment measuring axis | < 2Β° |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption typ. | 35 mA |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Voltage drop Vd | <3 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | IO-Link V1.1 |
| Baud rate | 38.4 kBaud (COM 2) |
| Cycle time | β₯ 8 ms |
| Process data length | 48 Bit |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Width / diameter | 12.9 mm |
| Height / length | 32.2 mm |
| Depth | 23 mm |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 β¦ +65 Β°C |
| Storage temperature | -40 β¦ +75 Β°C |
| Protection class | IP 67 |
| Output indicator | Yellow LED / red LED |
Call us for Baumer Ultrasonic Sensor With 4-Pin Cable U300.P50-GP2J.72CU part no: 11219505 at the best rates. Technical Attributes of U300.P50-GP2J.72CU, 11219505 are scanning range of 15 β¦ 500 mm. This IO-Link dual channel, Multiplex version sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 290 kHz. It features qTeach, line-Teach, IO-Link, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 β¦ 30 VDC and uses a Push-pull output circuit, supporting an output current of up to 100 mA. Designed in compact Rectangular housing, it measures 12.9 mm in width and 32.2 mm in height, making it suitable for various industrial applications. The housing is made from durable Plastic (ASA, PMMA), ensuring longevity in demanding environments. The sensor connects via an Cable 4 pin, 2 m, offering easy integration into your system. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Ultrasonic Sensor With 4-Pin Cable. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
