Baumer U300.EA0-GP2J.72CU Ultrasonic Sensor
The Baumer U300.EA0-GP2J.72CU Ultrasonic Sensor offers a Receiver, 0 β¦ 1000 mm sensing range, 12 β¦ 30 VDC supply voltage, LED green indication, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Ultrasonic Sensor category, this model belongs to the U300 Series.
| Brand | Baumer |
| Product Type | Ultrasonic Sensor |
| Model Number | U300.EA0-GP2J.72CU |
Baumer U300.EA0-GP2J.72CU Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Emitter / receiver | Receiver |
| Scanning range Sd | 0 β¦ 1000 mm |
| Scanning range far limit Sde | 0 β¦ 1000 mm |
| Version | IO-Link |
| Object size (at Sd = 50 mm) | > 4 cmΒ² |
| Hysteresis typ | 5 % Sde |
| Repeat accuracy | 1 mm |
| Temperature drift | < 2 % Sde |
| Response time ton | < 2 ms |
| Release time toff | < 2 ms |
| Adjustment | qTeach, line-Teach, IO-Link |
| Sonic frequency | 290 kHz |
| Alignment aid | Target indication flashing |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 35 mA |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Voltage drop Vd | <3 VDC |
| Residual ripple | < 10 % Vs |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Width / diameter | 12.9 mm |
| Height / length | 32.2 mm |
| Depth | 23 mm |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 β¦ +65 Β°C |
| Storage temperature | -40 β¦ +75 Β°C |
| Protection class | IP 67 |
Call us for Baumer 1000 mm Ultrasonic Sensor Receiver U300.EA0-GP2J.72CU part no: 11219512 at the best rates. Technical Attributes of U300.EA0-GP2J.72CU, 11219512 are Receiver configuration with a scanning range of 0 β¦ 1000 mm and sonic frequency of 290 kHz. The power-on indication is provided by a LED green, and the voltage supply range is between 12 β¦ 30 VDC. Designed with a Rectangular form factor, the housing is made of durable Plastic (ASA, PMMA) for reliable operation in various environments. The sensor has a width of 12.9 mm and a height of 32.2 mm with a connection facilitated through an Cable 4 pin, 2 m. It operates efficiently in temperatures ranging from -25 β¦ +65 Β°C, making it suitable for demanding industrial applications. Unlock Exclusive Pricing with a Quote for your requirement of Baumer 1000 mm Ultrasonic Sensor Receiver. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
