Baumer TDP 0,2 + OG 9, TDPZ 0,2 + OG 9 Rotary Encoder
The Baumer TDP 0,2 + OG 9, TDPZ 0,2 + OG 9 Rotary Encoder offers a ΓΈ115 mm size, 25 β¦ 5000 ppr, Optical method, and 2x terminal box connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Encoders.
| Voltage Supply | 9...30 VDC, 5 VDC Β±5 %, 9...26 VDC |
| Sensing Method | Optical |
| Size (flange) | ΓΈ115 mm |
| Connection | 2x terminal box |
Baumer TDP 0,2 + OG 9, TDPZ 0,2 + OG 9 Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 9...30 VDC, 5 VDC Β±5 %, 9...26 VDC |
| Consumption w/o load | β€100 mA |
| Pulses per revolution | 25 β¦ 5000 |
| Phase shift | 90 Β° Β±20Β° |
| Duty cycle | 40β¦60 % |
| Reference signal | Zero pulse, width 90Β° |
| Output frequency | β€120 kHz (β€300 kHz on request) |
| Output signals | K1, K2, K0 + inverted |
| Output stages | HTL-P (power linedriver), TTL/RS422 |
| Sensing method | Optical |
| Size (flange) | ΓΈ115 mm |
| Shaft type | ΓΈ11 mm solid shaft |
| Admitted shaft load | β€60 N axial, β€80 N radial |
| Protection EN 60529 | IP 55 |
| Rotor moment of inertia | 1.4 kgcmΒ² (TDP), 1.5 kgcmΒ² (TDPZ) |
| Material | Housing: aluminium die-cast, Shaft: stainless steel |
| Operating temperature | -30...+100 Β°C, -25...+100 Β°C (>3072 pulses) |
| Resistance | IEC 60068-2-6, Vibration 10 g, 10-2000 Hz, IEC 60068-2-27, Shock 100 g, 6 ms |
| Connection | 2x terminal box |
| Weight approx. | 3.3 kg (TDP), 3.5 kg (TDPZ) |
| Flange | EURO flange B10, Housing foot B3 |
| Operating speed | β€10000 rpm |
Get A Quote for Baumer Versatile Incremental Encoder TDP 0,2 + OG 9, TDPZ 0,2 + OG 9 at the best price. Here are the brief Technical Specifications of N/A, are voltage supply of 9...30 VDC, 5 VDC Β±5 %, 9...26 VDC, and consumption of β€100 mA without load. These encoders offer a range of pulses per revolution from 25 β¦ 5000 providing versatility in precision. The output stages include HTL-P (power linedriver), TTL/RS422 for flexible integration. The encoders come in a robust ΓΈ115 mm flange size and can handle shaft loads of up to β€60 N axial, β€80 N radial. With an operating torque of , they are designed for smooth performance. The Housing: aluminium die-cast, Shaft: stainless steel and operates in temperatures ranging from -30...+100 Β°C, -25...+100 Β°C (>3072 pulses). Connection options include 2x terminal box. It's Time to get a Quote for your requirement of Baumer Versatile Incremental Encoder. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
