Baumer PT20S Temperature Measurement
The Baumer PT20S Temperature Measurement offers a β€ 3000 mm sensor length. Manufactured by Baumer under the Baumer Temperature Measurement category, this model belongs to the VS Series.
| Brand | Baumer |
| Product Type | Temperature Measurement |
| Model Number | PT20S |
Baumer PT20S Temperature Measurement β Technical Specifications
| Specification | Value |
|---|---|
| Degree of protection (EN 60529) | Connector DIN EN 175301-803 A (DIN 43650 A), 4-pin:, IP65, Connector M12-A, 4-pin:, IP68 , with appropriate cable (336 h @ 10 mH2O), IP69K , with appropriate cable |
| Humidity | β€ 100 % RH , condensing |
| Vibration (sinusoidal) (EN 60068-2-6) | 1.6 mm p-p (2 β¦ 25 Hz), 4 g (25 β¦ 100 Hz), 1 octave / min., GL, test 2 |
| EMC | EN 61326-1 |
| Process temperature | Refer to section "Operating conditions" |
| Pt100 accuracy class (EN 60751) | 1/1 B Β± (0.3 + 0.005 Γ t)Β°C, 1/1 A Β± (0,15 + 0,002 Γ t)Β°C, 1/3 B Β± 1/3 Γ (0.3 + 0.005 Γ t)Β°C, 1/6 B Β± 1/6 Γ (0.3 + 0.005 Γ t)Β°C |
| Sensor length | β€ 3000 mm |
| Sensor tube material | AISI 316L (1.4404) |
| Surface roughness wetted parts | Ra β€ 0.8 Β΅m |
| Max. output error | β€ 0.06 % FSR @ 25 Β°C, Including input accuracy, output accuracy and repeatability |
| Temperature drift (by ambient) | < 0.025 K/K + 0.01 % FSR/K |
| Thermal response time, T90 | RTD element and transmitter combined, < 3.0 s , Γ3 mm, < 6.1 s , Γ6 mm |
| Output type | PNP, NPN, Digital (push-pull), 4 ... 20 mA, 2-wire, 20 ... 4 mA, 2-wire |
| Switching logic | Active high, Active low |
| Voltage drop | PNP: (+Vs - 1,2 V) Β± 0.5 V, Rload β₯ 10 kΞ©, NPN: (-Vs + 1,5 V) Β± 0.5 V, Rload β₯ 10 kΞ© |
| Current rating | 100 mA , max. |
| Off leak current | < 100 ΞΌA |
| Short circuit protection | Yes |
| Safety | cULus listed, E527512 |
Please speak to our Technical Engineer for Baumer Temperature Measurement PT20S at attractive prices. Technical Specs Summary of PT20S,includes rated Connector DIN EN 175301-803 A (DIN 43650 A), 4-pin:, IP65, Connector M12-A, 4-pin:, IP68 , with appropriate cable (336 h @ 10 mH2O), IP69K , with appropriate cable, providing excellent protection against dust and water. It operates reliably in humidity levels below β€ 100 % RH , condensing, making it suitable for demanding environments. Designed to withstand harsh conditions, enduring 1.6 mm p-p (2 β¦ 25 Hz), 4 g (25 β¦ 100 Hz), 1 octave / min., GL, test 2. The sensor length is β€ 3000 mm, ensuring a compact and efficient design. Built with AISI 316L (1.4404) stainless steel, the sensor tube offers superior corrosion resistance for industrial applications. The surface roughness of wetted parts is Ra β€ 0.8 Β΅m, ensuring optimal performance in precision measurement tasks. Match Your Needs with a Quote for your requirement of Temperature Measurement. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
