Baumer POG 11 G Rotary Encoder
The Baumer POG 11 G Rotary Encoder offers a ΓΈ115 mm size, 300 β¦ 5000 ppr, Optical method, and 2x terminal box, 3x terminal box (with option M) connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Incremental Encoder.
| Sensing Method | Optical |
| Connection | 2x terminal box, 3x terminal box (with option M) |
Baumer POG 11 G Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 9...30 VDC, 5 VDC Β±5 % |
| Consumption w/o load | β€100 mA |
| Pulses per revolution | 300 β¦ 5000 |
| Phase shift | 90 Β° Β±20Β° |
| Duty cycle | 40β¦60 % |
| Reference signal | Zero pulse, width 90Β° |
| Sensing method | Optical |
| Output signals | K1, K2, K0 + inverted, Error output (option EMS) |
| Output stages | HTL-P (power linedriver), TTL/RS422 |
| Size (flange) | ΓΈ115 mm |
| Shaft type | ΓΈ11 mm solid shaft |
| Admitted shaft load | β€300 N axial, β€450 N radial |
| Flange | EURO flange B10 |
| Protection EN 60529 | IP 67 |
| Operating speed | β€12000 rpm (mechanical) |
| Operating torque typ. | 2 Ncm |
| Rotor moment of inertia | 212 gcmΒ² |
| Material | Housing: aluminium die-cast, Shaft: stainless steel |
| Operating temperature | -40...+100 Β°C, -25...+100 Β°C (>3072 pulses) |
| Resistance | IEC 60068-2-6, Vibration 25 g, 10-2000 Hz, IEC 60068-2-27, Shock 300 g, 6 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions CX (C5-M) according to ISO 12944-2 |
| Connection | 2x terminal box, 3x terminal box (with option M) |
| Weight approx. | 2.5 kg, 2.7 kg (with option M) |
Mail Us for your needs in Baumer TTL Rotary Incremental Encoder POG 11 G part no: 11064874 with budget-friendly prices. The Main Technical Parameters of POG 11 G, 11064874 inludce voltage supply of 9...30 VDC, 5 VDC Β±5 % and pulses per revolution ranging from 300 β¦ 5000. The encoders provide a phase shift of 90 Β° Β±20Β° and a duty cycle of 40β¦60 %, with a Zero pulse, width 90Β°. Using Optical sensing technology, the encoders offer output signals including K1, K2, K0 + inverted, Error output (option EMS). The available output stages are HTL-P (power linedriver), TTL/RS422, ensuring versatile performance. The encoders come in an ΓΈ115 mm flange size and operate at speeds of up to -40...+100 Β°C, -25...+100 Β°C (>3072 pulses). Constructed with a durable Housing: aluminium die-cast, Shaft: stainless steel, they offer connections via 2x terminal box, 3x terminal box (with option M). Customize Your Experience with a Quote for your requirement of Baumer TTL Rotary Incremental Encoder. Experience the difference with our competitive pricing and superior support over other Suppliers.
