Baumer POG 11 Rotary Encoder
The Baumer POG 11 Rotary Encoder offers a ø115 mm size, 300 … 5000 ppr, Optical method, and Terminal box, 2x terminal box (with option M) connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Incremental Encoder.
| Sensing Method | Optical |
| Connection | Terminal box, 2x terminal box (with option M) |
Baumer POG 11 Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 9...30 VDC, 5 VDC ±5 % |
| Consumption w/o load | ≤100 mA |
| Pulses per revolution | 300 … 5000 |
| Phase shift | 90 ° ±20° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Optical |
| Output signals | K1, K2, K0 + inverted, Error output (option EMS) |
| Output stages | HTL-P (power linedriver), TTL/RS422 |
| Size (flange) | ø115 mm |
| Shaft type | ø11 mm solid shaft |
| Admitted shaft load | ≤300 N axial, ≤450 N radial |
| Flange | EURO flange B10 |
| Protection EN 60529 | IP 67 |
| Operating speed | ≤12000 rpm (mechanical) |
| Operating torque typ. | 2 Ncm |
| Rotor moment of inertia | 212 gcm² |
| Material | Housing: aluminium die-cast, Shaft: stainless steel |
| Operating temperature | -40...+100 °C, -25...+100 °C (>3072 pulses), -50...+100 °C (optional) |
| Resistance | IEC 60068-2-6, Vibration 25 g, 10-2000 Hz, IEC 60068-2-27, Shock 300 g, 6 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions CX (C5-M) according to ISO 12944-2 |
| Connection | Terminal box, 2x terminal box (with option M) |
| Weight approx. | 1.9 kg, 2.1 kg (with option M) |
Call us for Baumer Offshore And Salt Water Firm Encoder POG 11 part no: 11064874 at the best rates. Technical Attributes of POG 11, 11064874 are voltage supply of 9...30 VDC, 5 VDC ±5 % and pulses per revolution ranging from 300 … 5000. The encoders provide a phase shift of 90 ° ±20° and a duty cycle of 40…60 %, with a Zero pulse, width 90°. Using Optical sensing technology, the encoders offer output signals including K1, K2, K0 + inverted, Error output (option EMS). The available output stages are HTL-P (power linedriver), TTL/RS422, ensuring versatile performance. The encoders come in an ø115 mm flange size and operate at speeds of up to -40...+100 °C, -25...+100 °C (>3072 pulses), -50...+100 °C (optional). Constructed with a durable Housing: aluminium die-cast, Shaft: stainless steel, they offer connections via Terminal box, 2x terminal box (with option M). Unlock Exclusive Pricing with a Quote for your requirement of Baumer Offshore And Salt Water Firm Encoder. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
