Baumer POG 10 + ESL 93 Rotary Encoder
The Baumer POG 10 + ESL 93 Rotary Encoder offers a ø115 mm size, 300 … 5000 ppr, Optical method, and 2x terminal box, 3x terminal box (with option M) connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Encoders.
| Voltage Supply | 12 VDC ±10 % |
| Sensing Method | Optical |
| Size (flange) | ø115 mm |
| Connection | 2x terminal box, 3x terminal box (with option M) |
Baumer POG 10 + ESL 93 Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 12 VDC ±10 % |
| Consumption w/o load | ≤5 mA |
| Pulses per revolution | 300 … 5000 |
| Phase shift | 90 ° ±20° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° |
| Output frequency | ≤120 kHz, ≤300 kHz (on request) |
| Output signals | K1, K2, K0 + inverted, Error output (option EMS) |
| Output stages | HTL-P (power linedriver), TTL/RS422 |
| Sensing method | Optical |
| Switching accuracy | ± 4 % (≤1500 rpm), ± 2 % (>1500 rpm) |
| Switching outputs | 3 outputs, speed control |
| Size (flange) | ø115 mm |
| Shaft type | ø11 mm solid shaft |
| Admitted shaft load | ≤300 N axial, ≤450 N radial |
| Protection EN 60529 | IP 66 |
| Range of switching speed (ns) | 3x 200...5000 rpm |
| Operating torque typ. | 3 Ncm |
| Rotor moment of inertia | 220 gcm² |
| Material | Housing: aluminium die-cast, Shaft: stainless steel |
| Operating temperature | -20...+85 °C |
| Resistance | IEC 60068-2-6, Vibration 10 g, 10-2000 Hz, IEC 60068-2-27, Shock 100 g, 11 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions C4 according to ISO 12944-2 |
| Connection | 2x terminal box, 3x terminal box (with option M) |
| Weight approx. | 2.7 kg, 2.9 kg (with option M) |
| Flange | EURO flange B10 |
| Operating speed | ≤5000 rpm |
| Switching delay time | ≤40 ms |
Mail Us for your needs in Baumer Pulse Incremental Encoder POG 10 + ESL 93 with budget-friendly prices. The Main Technical Parameters of N/A, inludce voltage supply of 12 VDC ±10 %, and consumption of ≤5 mA without load. These encoders offer a range of pulses per revolution from 300 … 5000 providing versatility in precision. The output stages include HTL-P (power linedriver), TTL/RS422 for flexible integration. The encoders come in a robust ø115 mm flange size and can handle shaft loads of up to ≤300 N axial, ≤450 N radial. With an operating torque of 3 Ncm, they are designed for smooth performance. The Housing: aluminium die-cast, Shaft: stainless steel and operates in temperatures ranging from -20...+85 °C. Connection options include 2x terminal box, 3x terminal box (with option M). Customize Your Experience with a Quote for your requirement of Baumer Pulse Incremental Encoder. Experience the difference with our competitive pricing and superior support over other Suppliers.
