Baumer PMG10 - Incremental Rotary Encoder
The Baumer PMG10 - Incremental Rotary Encoder offers a ΓΈ115 mm size, 1 β¦ 131072 ppr, Magnetic method, and Terminal box, Flange connector M23 connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Incremental Encoder.
| Sensing Method | Magnetic |
| Switching Outputs | 1 output (Open collector) |
| Connection | Terminal box, Flange connector M23 |
Baumer PMG10 - Incremental Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 4.75...30 VDC |
| Short-circuit proof | Yes |
| Consumption w/o load | β€100 mA |
| Initializing time | β€500 ms after power on |
| Pulses per revolution | 1 β¦ 131072 |
| Phase shift | 90 Β° Β±20Β° |
| Duty cycle | 40β¦60 % |
| Reference signal | Zero pulse, width 90Β° |
| Sensing method | Magnetic |
| Output signals | A+, B+, R+, A-, B-, R-, Error output nE+, nE- |
| Output stages | TTL/HTL (Vin = Vout) |
| Programming interface | RS485 (β€600 m) |
| Programmable parameters | Pulse number, Switch-off and switch-on speeds, Switching delay time |
| Diagnostic function | Function control |
| Status indicator | 4 LEDs in device back side |
| Switching accuracy | Β± 2 % (or 1 Digit) |
| Switching outputs | 1 output (Open collector) |
| Output switching capacity | 30 VDC; β€100 mA |
| Switching hysteresis | 10 β¦ 100 % adjustable |
| Switching delay time | β€20 ms |
| Size (flange) | ΓΈ115 mm |
| Shaft type | ΓΈ11 mm solid shaft |
| Admitted shaft load | β€450 N axial, β€650 N radial |
| Flange | EURO flange B10, Housing foot B3 |
| Protection EN 60529 | IP 66 / IP 67 |
| Operating speed | β€12000 rpm |
| Range of switching speed | ns (off) = Β±2...12000 rpm, factory setting 6000 rpm |
| Operating torque typ. | 10 Ncm |
| Rotor moment of inertia | 1 kgcmΒ² |
| Material | Housing: aluminium alloy, Shaft: stainless steel |
| Operating temperature | -40...+95 Β°C |
| Relative humidity | 95 % non-condensing |
| Resistance | IEC 60068-2-6, Vibration 30 g, 10-2000 Hz, IEC 60068-2-27, Shock 400 g, 1 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions CX (C5-M) according to ISO 12944-2 |
| Connection | Terminal box, Flange connector M23 |
| Weight approx. | 1.9 kg (depending on version) |
Call us for Baumer Encoder With TTL PMG10 - Incremental part no: 11064874 at the best rates. Technical Attributes of PMG10 - Incremental, 11064874 are voltage supply of 4.75...30 VDC and pulses per revolution ranging from 1 β¦ 131072. The encoders provide a phase shift of 90 Β° Β±20Β° and a duty cycle of 40β¦60 %, with a Zero pulse, width 90Β°. Using Magnetic sensing technology, the encoders offer output signals including A+, B+, R+, A-, B-, R-, Error output nE+, nE-. The available output stages are TTL/HTL (Vin = Vout), ensuring versatile performance. The encoders come in an ΓΈ115 mm flange size and operate at speeds of up to -40...+95 Β°C. Constructed with a durable Housing: aluminium alloy, Shaft: stainless steel, they offer connections via Terminal box, Flange connector M23. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Encoder With TTL. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
