Baumer PL240-140T54.CV0200.00: Level Sensors
Technical Specifications of Baumer PL240-140T54.CV0200.00 11722484:
| Nominal sensing distance Sn | 6 mm |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Output circuit | Push-pull |
| Output current | β€50 mA |
Baumer Level Sensors PL240-140T54.CV0200.00 Technical Specifications
| Specification | Value |
|---|
| Special type | Adhesion compensation |
| Nominal sensing distance Sn | 6 mm |
| Nominal sensing distance Sn adjustable | 0.5 β¦ 6 mm |
| Mounting type | Flush with container outer wall |
| Sensitivity adjustment | Teach-in: remote |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Measurement type | Contactless |
| Detection of non-conductive media | Yes (water-based liquids) |
| Fill level detection through container | Yes |
| Liquids in direct contact | No |
| Object detection / bulk goods | No |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 70 mA |
| Output circuit | Push-pull |
| Output current | β€50 mA |
| Voltage drop Vd | <3 VDC |
| Switching frequency | 5 Hz |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | PP/PA |
| Dimension | 40 mm |
| Housing length | 40 mm |
| Depth | 10 mm |
| Connection types | Cable PVC 4 x 0,14, 2 m |
| Operating temperature | -25 β¦ +60 Β°C |
| Storage temperature | -40 β¦ +80 Β°C |
| Shock (semi-sinusoidal) | IEC 60068-2-27:2009, 30 g / 11 ms, 6 jolts per axis and direction |
| Vibration (sinusoidal) | IEC 60068-2-6:2008, 1 mm p-p at f = 10 - 55 Hz, duration 5 min per axis, 30 min endurance at f = 55 Hz per axis |
| Protection class | IP 67 |
