OXS100-R10V.E02: 11728841 - Baumer Machine Vision Sensor Technology
Baumer Machine Vision Sensor Technology OXS100-R10V.E02 11728841:
| Dimensions (W x H x D) | 36 mm x 80 mm x 70 mm |
| Measurement range MR | 100 mm |
| Switching outputs | 2 x Outputs (Push-Pull) |
Baumer Machine Vision Sensor Technology OXS100-R10V.E02, 11728841 Technical Specifications:
| Specification | Value |
|---|---|
| Measurement range MR | 100 mm |
| Clearance distance | 150 mm |
| Working range (Sdc ... Sde) | 150 ... 250 mm |
| Reference distance | 200 mm |
| Field of view (@Sdc ... Sde) | 75 ... 125 mm |
| Resolution X (@Sdc ... Sde) | 125 ... 210 Β΅m |
| Profiles per second | 200 ... 500 Hz |
| Profile points | 630 pixel |
| Resolution Z (@Sdc ... Sde) | 24 ... 36 Β΅m |
| Repeat accuracy Z | 20 Β΅m |
| Linearity deviation Z | Β± 0.2 % MR |
| Temperature drift | Β± 0.08 %Sde/K |
| Laser class | 1 |
| Laser wavelength | Red (660 nm) |
| Max. laser power | 2.4 mW |
| Light point shape (at reference distance) | Line Length (x) 130 mm, Line Width (z) 350 Β΅m |
| Software / parametrisation | Integrated Webserver for parametrisation |
| Interfaces / output circuit | Serial RS485, 2 x Switching Output, Analog Output |
| Protocols | Modbus RTU, IO-Link |
| Voltage supply range +Vs | 18 ... 30 VDC |
| Analog output signal | 4-20mA, 2-10mA, 0-10V, 0-5V |
| Switching outputs | 2 x Outputs (Push-Pull) |
| Power supply | typ. 2.4W (100 mA max at 24 V) |
| Electrical connection | M12, 12-pin, A-coded, male |
| Ethernet connection | USB-C for parametrisation |
| Trigger input specification | Low Level: < 2.5 V, High Level: 8 V ... +Ub |
| Material | Case: Die-cast zinc, Front Cover: PMMA |
| Dimensions (W x H x D) | 36 mm x 80 mm x 70 mm |
| Width | 36 mm |
| Height | 80 mm |
| Depth | 70 mm |
| Weight | 450 g |
| Ambient temperature | 0 ... + 45 Β°C |
| Storage temperature | - 10 ... + 60 Β°C |
| Ambient humidity | 20 ... 85 % |
| Protection class (IEC 60529) | IP 65 |
| Vibration (sinusoidal) | 1 mm p-p at f = 10 - 55 Hz, duration 5 min per axis, 30 min endurance at f = 55 Hz per axis, IEC 60068-2-6:2008 |
| Shock (semi-sinusoidal) | 30 g / 11 ms, 6 jolts per axis and direction, IEC 60068-2-27:2009 |
| Ambient light immunity | < 25 kLux |
| Conformity | CE, UL |
Obtain a Quote for Baumer Machine Vision Sensor Technology OXS100-R10V.E02 part no: 11728841 at economical prices. Specifications Overview for OXS100-R10V.E02, 11728841 reveals measurement range (MR) of 100 mm and a clearance distance of 150 mm. The field of view spans 75 ... 125 mm with a resolution X of 125 ... 210 Β΅m and profile points of 630 pixel. The resolution Z ranges from 24 ... 36 Β΅m, with a repeat accuracy of 20 Β΅m. The sensor uses a red laser with a wavelength of Red (660 nm) and a maximum laser power of 2.4 mW. Operating on a voltage supply range of 18 ... 30 VDC, the sensor supports analog output signals such as 4-20mA, 2-10mA, 0-10V, 0-5V. It offers 2 x Outputs (Push-Pull) switching outputs and is equipped with an M12, 12-pin, A-coded, male connector and USB-C for parametrisation. The sensor is housed in a durable Case: Die-cast zinc, Front Cover: PMMA front cover, and its dimensions are 36 mm x 80 mm x 70 mm. Take the First Step with a Quote for your requirement of Baumer Machine Vision Sensor Technology. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
