Baumer OR18W.ZI-PW1P.9VO/B005 Photoelectric Sensor
The Banner OR18W.ZI-PW1P.9VO/B005 Photoelectric Sensor offers a 18 mm diameter, < 800 mm sensing distance, PNP output circuit, and Connector M12 4 pin connection type. Manufactured by Banner under the Banner Photoelectric Sensor category, this model belongs to the O300 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | OR18W.ZI-PW1P.9VO/B005 |
Baumer OR18W.ZI-PW1P.9VO/B005 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Intensity difference |
| Sensing distance Tw | < 800 mm |
| Sensing distance adjustment | Potentiometer, 270Β° |
| Light source | Pulsed infrared diode |
| Wave length | 880 nm |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Output current | 100 mA |
| Width / diameter | 18 mm |
| Height / length | 67.2 mm |
| Design | Cylindrical threaded |
| Housing material | Stainless steel 1.4404 (V4A) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Protection class | IP 67/69K |
| Operating temperature | -25 β¦ +55 Β°C |
| Alignment / soiled lens indicator | LED green |
| Output indicator | LED yellow |
Obtain a Quote for Baumer Sensor In Laser Class Safety OR18W.ZI-PW1P.9VO/B005 part no: 11157849 at economical prices. Specifications Overview for OR18W.ZI-PW1P.9VO/B005, 11157849 reveals Intensity difference Sensor, engineered for precise detection with a sensing distance of < 800 mm. The sensor utilizes a Pulsed infrared diode with a wavelength of 880 nm, ensuring accurate and rapid response times of less than < 1 ms. It operates within a voltage supply range of 12 β¦ 30 VDC, offering Light / dark operate functionality with a PNP output circuit capable of handling up to 100 mA of output current. Measuring 18 mm in width and 67.2 mm in height, the compact Cylindrical threaded design is housed in durable Stainless steel 1.4404 (V4A) materials. The connection is made via a Connector M12 4 pin. Take the First Step with a Quote for your requirement of Baumer Sensor In Laser Class Safety. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
