Baumer OR18W.GR-NW1P.9VO Photoelectric Sensor
The Baumer OR18W.GR-NW1P.9VO Photoelectric Sensor offers a Cylindrical threaded design, 40 β¦ 120 mm sensing distance, NPN output, and Connector M12 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the Background Suppression type.
| Sensing distance Tw | 40 β¦ 120 mm |
| Sensing range Tb | 5 β¦ 120 mm |
| Output circuit | NPN |
| Connection types | Connector M12 4 pin |
Baumer OR18W.GR-NW1P.9VO Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Background suppression |
| Sensing distance Tw | 40 β¦ 120 mm |
| Sensing range Tb | 5 β¦ 120 mm |
| Power on indication | LED green |
| Output indicator | LED yellow |
| Sensing distance adjustment | Mechanical, 4 turn |
| Suppression of reciprocal influence | No |
| Light source | Pulsed red LED |
| Wave length | 660 nm |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 71.9 mm |
| Design | Cylindrical threaded |
| Housing material | Stainless steel 1.4404 (V4A), plastic (ABS TERLURAN) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Protection class | IP 67/69K |
| Operating temperature | -25 β¦ +55 Β°C |
Give Us a Call for Baumer Connector M12 4-pin Sensor OR18W.GR-NW1P.9VO part no: 11157857 at the lowest pricing. In-depth Technical Analysis of OR18W.GR-NW1P.9VO, 11157857 feature Background suppression Sensor, engineered for precise detection with a sensing distance (Tw) of 40 β¦ 120 mm. The sensor features Mechanical, 4 turn adjustment for flexible setup and utilizes an Pulsed red LED light source with a wavelength of 660 nm. It boasts a fast response time of less than < 1 ms, and operates within a voltage supply range of 12 β¦ 30 VDC, with a typical current consumption of 30 mA. The output function supports Light / dark operate with a NPN output circuit and can handle an output current of up to 100 mA. Measuring 18 mm in width, 71.9 mm in height, and in depth, this compact Cylindrical threaded sensor is connected via a Connector M12 4 pin. Elevate Your Project with a Quote for your requirement of Baumer Connector M12 4-pin Sensor. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
