Baumer OR18W.EI-PW1P.9VO Photoelectric Sensor
The Baumer OR18W.EI-PW1P.9VO Photoelectric Sensor offers a Cylindrical threaded design, 20 m nominal range, Receiver, PNP output, and Connector M12 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | OR18W.EI-PW1P.9VO |
Baumer OR18W.EI-PW1P.9VO Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 13 m |
| Nominal range Sn | 20 m |
| Alignment / soiled lens indicator | LED green |
| Output indicator | LED yellow |
| Sensitivity adjustment | Potentiometer, 270Β° |
| Response time / release time | < 2 ms |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 67.2 mm |
| Design | Cylindrical threaded |
| Housing material | Stainless steel 1.4404 (V4A) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Operating temperature | -25 β¦ +55 Β°C |
| Protection class | IP 67/69K |
Talk to Our Engineer for Baumer PNP Receiver Through-beam Sensor OR18W.EI-PW1P.9VO part no: 11157851 with exclusive offers. Core System Specifications of OR18W.EI-PW1P.9VO, 11157851 are Through beam sensor Model Type designed for precise object detection with a nominal range of 20 m. This sensor operates on a voltage supply range of 12 β¦ 30 VDC, with a maximum current consumption of 40 mA and a typical consumption of 30 mA. The compact Cylindrical threaded design features dimensions of 18 mm in width, 67.2 mm in height, and in depth, ensuring easy installation in various industrial environments. The housing is made from durable Stainless steel 1.4404 (V4A) offering robustness for demanding applications. The sensor connects via a Connector M12 4 pin making it suitable for seamless integration into your system. With a Receiver. Don't Miss Out on a Quote for your requirement of Baumer PNP Receiver Through-beam Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
