Baumer OR18.ZL-NV1P.7BCV/B013 Photoelectric Sensor
The Banner OR18.ZL-NV1P.7BCV/B013 Photoelectric Sensor offers a 18 mm diameter, 10 β¦ 300 mm sensing distance, NPN complementary output circuit, and Cable 4 pin, 2 m connection type. Manufactured by Banner under the Banner Photoelectric Sensor category, this model belongs to the O300 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | OR18.ZL-NV1P.7BCV/B013 |
Baumer OR18.ZL-NV1P.7BCV/B013 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Intensity difference |
| Sensing distance Tw | 10 β¦ 300 mm |
| Power on indication | LED green |
| Sensing distance adjustment | Potentiometer, 270Β° |
| Distance to focus | 100 mm |
| Light source | Pulsed red laser diode |
| Laser class | 1 |
| Wave length | 630 nm |
| Response time / release time | < 0.34 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 45 mA |
| Current consumption typ. | 35 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN complementary |
| Output current | 100 mA |
| Width / diameter | 18 mm |
| Height / length | 77 mm |
| Design | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Protection class | IP 67 |
| Operating temperature | -10 β¦ +55 Β°C |
| Output indicator | LED yellow |
Send Your Inquiry for Baumer Precise Sensor For Light Intensity OR18.ZL-NV1P.7BCV/B013 part no: 11157806 with cost-effective solutions. Essential Technical Specs of OR18.ZL-NV1P.7BCV/B013, 11157806 are Intensity difference Sensor, engineered for precise detection with a sensing distance of 10 β¦ 300 mm. The sensor utilizes a Pulsed red laser diode with a wavelength of 630 nm, ensuring accurate and rapid response times of less than < 0.34 ms. It operates within a voltage supply range of 10 β¦ 30 VDC, offering Light / dark operate functionality with a NPN complementary output circuit capable of handling up to 100 mA of output current. Measuring 18 mm in width and 77 mm in height, the compact Cylindrical threaded design is housed in durable Brass nickel plated materials. The connection is made via a Cable 4 pin, 2 m. Capture the Best Deal with a Quote for your requirement of Baumer Precise Sensor For Light Intensity. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
