Baumer OR18.RR.T-NW1P.71O Photoelectric Sensor
The Baumer OR18.RR.T-NW1P.71O Photoelectric Sensor offers a Cylindrical threaded design, 0.8 m nominal range, 12 … 30 VDC supply voltage, NPN output, and Connector M12 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | OR18.RR.T-NW1P.71O |
Baumer OR18.RR.T-NW1P.71O Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed red LED |
| Actual range Sb | 0.5 m |
| Nominal range Sn | 0.8 m |
| Polarization filter | Yes |
| Output indicator | LED yellow |
| Sensitivity adjustment | Potentiometer, 270° |
| Wave length | 660 nm |
| Suppression of reciprocal influence | Yes |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN |
| Output current | 100 mA |
| Width / diameter | 18 mm |
| Height / length | 67.2 mm |
| Design | Cylindrical threaded |
| Housing material | Plastic (ABS TERLURAN) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Operating temperature | -25 … +55 °C |
| Protection class | IP 67 |
Ask for the Pricing of Baumer Cylindrical Threaded Design Sensor For Industry OR18.RR.T-NW1P.71O part no: 11157789 at unbeatable prices. Detailed Specifications of OR18.RR.T-NW1P.71O, 11157789 feature Retro-reflective sensor designed for precision detection with an actual range of 0.5 m and a nominal range of 0.8 m. The sensor features a Pulsed red LED light source with a wavelength of 660 nm, ensuring accurate performance with a response time of less than < 1 ms. It operates within a voltage supply range of 12 … 30 VDC, supporting both Light / dark operate functions through a NPN output circuit capable of handling up to 100 mA of output current. Measuring 18 mm in width and 67.2 mm in height, the sensor’s compact Cylindrical threaded design is housed in durable Plastic (ABS TERLURAN) materials, making it ideal for industrial environments. The sensor connects via a Connector M12 4 pin for reliable integration. Now's the Time to Secure a Quote for your requirement of Baumer Cylindrical Threaded Design Sensor For Industry. We're committed to offering more favorable pricing and more responsive support than other Traders.
