Baumer OR18.GR-NW1P.71O Photoelectric Sensor
The Baumer OR18.GR-NW1P.71O Photoelectric Sensor offers a Cylindrical threaded design, 40 β¦ 120 mm sensing distance, NPN output, and Connector M12 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the Background Suppression type.
| Sensing distance Tw | 40 β¦ 120 mm |
| Sensing range Tb | 5 β¦ 120 mm |
| Output circuit | NPN |
| Connection types | Connector M12 4 pin |
Baumer OR18.GR-NW1P.71O Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Background suppression |
| Sensing distance Tw | 40 β¦ 120 mm |
| Sensing range Tb | 5 β¦ 120 mm |
| Power on indication | LED green |
| Output indicator | LED yellow |
| Light source | Pulsed red LED |
| Wave length | 660 nm |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 12 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 71.9 mm |
| Design | Cylindrical threaded |
| Housing material | Plastic (ABS TERLURAN) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Protection class | IP 67 |
| Operating temperature | -25 β¦ +55 Β°C |
Get A Quote for Baumer Pulsed Red LED Diffuse Sensor OR18.GR-NW1P.71O part no: 11157842 at the best price. Here are the brief Technical Specifications of OR18.GR-NW1P.71O, 11157842 are Background suppression Sensor, engineered for precise detection with a sensing distance (Tw) of 40 β¦ 120 mm. The sensor features adjustment for flexible setup and utilizes an Pulsed red LED light source with a wavelength of 660 nm. It boasts a fast response time of less than < 1 ms, and operates within a voltage supply range of 12 β¦ 30 VDC, with a typical current consumption of 30 mA. The output function supports Light / dark operate with a NPN output circuit and can handle an output current of up to 100 mA. Measuring 18 mm in width, 71.9 mm in height, and in depth, this compact Cylindrical threaded sensor is connected via a Connector M12 4 pin. It's Time to get a Quote for your requirement of Baumer Pulsed Red LED Diffuse Sensor. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
