Baumer OR18.EL-NV1P.7BCV Photoelectric Sensor
The Baumer OR18.EL-NV1P.7BCV Photoelectric Sensor offers a Cylindrical threaded design, 60 m nominal range, Receiver, NPN complementary output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | OR18.EL-NV1P.7BCV |
Baumer OR18.EL-NV1P.7BCV Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 55 m |
| Nominal range Sn | 60 m |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Sensitivity adjustment | Potentiometer, 270Β° |
| Response time / release time | < 0.34 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 45 mA |
| Current consumption typ. | 35 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN complementary |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 77 mm |
| Design | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -10 β¦ +55 Β°C |
| Protection class | IP 67 |
Ask for the Pricing of Baumer Precision Sensor For Industrial Use OR18.EL-NV1P.7BCV part no: 11157820 at unbeatable prices. Detailed Specifications of OR18.EL-NV1P.7BCV, 11157820 feature Through beam sensor Model Type designed for precise object detection with a nominal range of 60 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 45 mA and a typical consumption of 35 mA. The compact Cylindrical threaded design features dimensions of 18 mm in width, 77 mm in height, and in depth, ensuring easy installation in various industrial environments. The housing is made from durable Brass nickel plated offering robustness for demanding applications. The sensor connects via a Cable 4 pin, 2 m making it suitable for seamless integration into your system. With a Receiver. Now's the Time to Secure a Quote for your requirement of Baumer Precision Sensor For Industrial Use. We're committed to offering more favorable pricing and more responsive support than other Traders.
