Baumer ONDK 25G6911 Photoelectric Sensor
The Banner ONDK 25G6911 Photoelectric Sensor offers a 23.4 mm diameter, Pulsed red laser diode light source, Push-pull output circuit, and Cable, L=2 m connection type. Manufactured by Banner under the Banner Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Banner |
| Product Type | Photoelectric Sensor |
| Model Number | ONDK 25G6911 |
Baumer ONDK 25G6911 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Light barrier |
| Version | Standard object detection |
| Background position Sde | 100 β¦ 1900 mm |
| Scanning range Sa | 97% ... 83% Sde |
| Power on indication | LED green |
| Alignment / soiled lens indicator | Flashing light indicator |
| Sensing distance adjustment | Teach-in |
| Light source | Pulsed red laser diode |
| Wave length | 656 nm |
| Response time / release time | < 10 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 80 mA |
| Voltage drop Vd | <3.5 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Width / diameter | 23.4 mm |
| Height / length | 63 mm |
| Depth | 45 mm |
| Design | Rectangular |
| Housing material | Plastic (SAN LURAN 378P) |
| Front (optics) | PMMA |
| Connection types | Cable, L=2 m |
| Protection class | IP 67 |
| Operating temperature | 0 β¦ +50 Β°C |
Call us for Baumer Industrial Sensor With 2M Cable Design ONDK 25G6911 part no: 11079993 at the best rates. Technical Attributes of ONDK 25G6911, 11079993 are Light barrier, Type offering superior precision and reliability. This sensor features a scanning range (Sa) 97% ... 83% Sde with adjustable sensing distance Teach-in. It operates using a Pulsed red laser diode light source with a wave length of 656 nm. The voltage supply range is 10 β¦ 30 VDC, with a current consumption of 80 mA. The voltage drop (Vd) is less than <3.5 VDC, with Light / dark operate output functions. The output circuit is Push-pull, and the output current is rated at 100 mA. With a width of 23.4 mm and a height of 63 mm, the housing is made of durable Plastic (SAN LURAN 378P). This sensor is equipped with a Cable, L=2 m connection. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Industrial Sensor With 2M Cable Design. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
