Baumer OM70-P0070.HH0048.EK Ultrasonic Distance Sensor
The Baumer OM70-P0070.HH0048.EK Laser Distance Sensor offers a Rectangular, front view design, 30 β¦ 70 mm scanning range, Analog and digital output, and Connector M12 8 pin & M12 4 pin connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OM70 Series.
| Measuring distance Sd | 30 β¦ 70 mm |
| Measuring range Mr | 40 mm |
| Output circuit | Analog and digital |
Baumer OM70-P0070.HH0048.EK Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Distance measuring |
| Measuring distance Sd | 30 β¦ 70 mm |
| Measuring range Mr | 40 mm |
| Adjustment | Webserver, Ethernet TCP/IP |
| Power on indication | LED green |
| Output indicator | LED yellow / LED red |
| Repeat accuracy | 0.1 β¦ 0.3 Β΅m |
| Linearity error | Β± 0.06 % Mr |
| Beam type | Point |
| Temperature drift | 0,01 % Sde/K |
| Light source | Pulsed red laser diode |
| Wave length | 660 nm |
| Response delay | 0.8 ms |
| Measuring frequency | 2000 Hz |
| Voltage supply range +Vs | 15 β¦ 28 VDC |
| Current consumption max. (no load) | 75 mA |
| Output circuit | Analog and digital |
| Interface | Ethernet TCP/IP |
| Protocol | Profinet (Class B), Modbus TCP, OPC UA, UDP streaming, EtherNet/IP |
| Width / diameter | 26 mm |
| Height / length | 74 mm |
| Depth | 55 mm |
| Design | Rectangular, front view |
| Housing material | Aluminum |
| Front (optics) | Glass |
| Connection types | Connector M12 8 pin & M12 4 pin |
| Ambient light immunity | < 28 kLux |
| Protection class | IP 67 |
| Operating temperature | -10 β¦ +50 Β°C |
| Output signal | 4 ... 20 mA / 2 ... 10 mA / 0 ... 10 VDC / 0 ... 5 VDC |
| Output current | 100 mA |
| Switching output | Push-pull |
| Weight | 135 g |
Talk to Our Engineer for Baumer Ethernet TCP/IP Distance Sensor OM70-P0070.HH0048.EK part no: 11216522 with exclusive offers. Core System Specifications of OM70-P0070.HH0048.EK, 11216522 are distance range of 30 β¦ 70 mm. This sensor utilizes Touch Display, RS485 with a LED green power-on indicator. The Point type is point-based, using a Pulsed red laser diode at a wavelength of 660 nm. The sensor operates within a voltage supply range of 15 β¦ 28 VDC, with a maximum current consumption of 75 mA. The compact Rectangular, front view design measures 26 mm in width, 74 mm in height, and 55 mm in depth, offering easy installation in tight spaces. Constructed with durable Aluminum housing, the front optics are made of Glass for enhanced protection. The sensor connects via an Connector M12 8 pin making it ideal for industrial applications requiring high precision. Don't Miss Out on a Quote for your requirement of Baumer Ethernet TCP/IP Distance Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
