Baumer OM30.GM-PLZZB.7WN Photoelectric Sensor
The Baumer OM30.GM-PLZZB.7WN Photoelectric Sensor offers a Rectangular, front view design, 50 β¦ 550 mm sensing distance, PNP output, and Connector M8 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the Background Suppression type.
| Sensing distance Tw | 50 β¦ 550 mm |
| Sensing range Tb | 50 β¦ 550 mm |
| Output circuit | PNP |
| Connection types | Connector M8 4 pin |
Baumer OM30.GM-PLZZB.7WN Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Background suppression |
| Sensing distance Tw | 50 β¦ 550 mm |
| Sensing range Tb | 50 β¦ 550 mm |
| Power on indication | LED green |
| Output indicator | LED red |
| Light source | Pulsed red laser diode |
| Wave length | 660 nm |
| Response time / release time | < 6.7 ms |
| Voltage supply range +Vs | 12 β¦ 28 VDC |
| Current consumption max. (no load) | 50 mA |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Output current | <100 mA |
| Short circuit protection | Yes |
| Width / diameter | 13.6 mm |
| Height / length | 49 mm |
| Depth | 40.3 mm |
| Design | Rectangular, front view |
| Housing material | Die-cast zinc |
| Front (optics) | Glass |
| Connection types | Connector M8 4 pin |
| Protection class | IP 67 |
| Operating temperature | -10 β¦ +50 Β°C |
Talk to Our Engineer for Baumer Sensor With Io-Link Output Function OM30.GM-PLZZB.7WN part no: 11257432 with exclusive offers. Core System Specifications of OM30.GM-PLZZB.7WN, 11257432 are Background suppression Sensor, engineered for precise detection with a sensing distance (Tw) of 50 β¦ 550 mm. The sensor features adjustment for flexible setup and utilizes an Pulsed red laser diode light source with a wavelength of 660 nm. It boasts a fast response time of less than < 6.7 ms, and operates within a voltage supply range of 12 β¦ 28 VDC, with a typical current consumption of . The output function supports Light / dark operate with a PNP output circuit and can handle an output current of up to <100 mA. Measuring 13.6 mm in width, 49 mm in height, and 40.3 mm in depth, this compact Rectangular, front view sensor is connected via a Connector M8 4 pin. Don't Miss Out on a Quote for your requirement of Baumer Sensor With Io-Link Output Function. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
