Baumer OGS 71 Rotary Encoder
The Baumer OGS 71 Rotary Encoder offers a ΓΈ58 mm size, ppr, Optical method, and Connecting terminal connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Incremental Encoder.
| Sensing Method | Optical |
| Connection | Connecting terminal |
Baumer OGS 71 Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 5 VDC Β±10 %, 9...30 VDC |
| Consumption w/o load | β€90 mA |
| Phase shift | 90 Β° |
| Reference signal | Zero pulse, width 90Β° |
| Sensing method | Optical |
| Output signals | K1, K2, K0 + inverted |
| Output stages | SinCos 1 Vpp |
| Size (flange) | ΓΈ58 mm |
| Shaft type | ΓΈ6 mm solid shaft |
| Admitted shaft load | β€30 N axial, β€40 N radial |
| Flange | Synchro flange |
| Protection EN 60529 | IP 66 |
| Operating speed | β€10000 rpm (mechanical) |
| Operating torque typ. | 1 Ncm |
| Rotor moment of inertia | 25 gcmΒ² |
| Material | Housing: aluminium die-cast, Shaft: stainless steel |
| Operating temperature | -20...+85 Β°C |
| Resistance | IEC 60068-2-6, Vibration 10 g, 10-2000 Hz, IEC 60068-2-27, Shock 300 g, 6 ms |
| Connection | Connecting terminal |
| Weight approx. | 350 g |
Obtain a Quote for Baumer Pulse Encoder With High Resolution OGS 71 part no: at economical prices. Specifications Overview for OGS 71, reveals voltage supply of 5 VDC Β±10 %, 9...30 VDC and pulses per revolution ranging from . The encoders provide a phase shift of 90 Β° and a duty cycle of , with a Zero pulse, width 90Β°. Using Optical sensing technology, the encoders offer output signals including K1, K2, K0 + inverted. The available output stages are SinCos 1 Vpp, ensuring versatile performance. The encoders come in an ΓΈ58 mm flange size and operate at speeds of up to -20...+85 Β°C. Constructed with a durable Housing: aluminium die-cast, Shaft: stainless steel, they offer connections via Connecting terminal. Take the First Step with a Quote for your requirement of Baumer Pulse Encoder With High Resolution. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
