Baumer OE40.F22-YIN Edge Sensor
The Baumer OE40.F22-YIN Edge Sensor offers a 22 mm range, output, 12 … 28 VDC supply voltage, and connection. Manufactured by Baumer under the Baumer Edge Sensor category, this model belongs to the OE/OX Series.
| Brand | Baumer |
| Product Type | Edge Sensor |
| Model Number | OE40.F22-YIN |
Baumer OE40.F22-YIN Edge Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Type | Edge position, transparent edge, width, gap, object center, gap center |
| Version | Performance |
| Measuring range Mr | 22 mm |
| Measuring distance (to object) | < 200 mm |
| Adjustment | IO-Link |
| Power on indication | LED green |
| Output indicator | LED yellow |
| Repeat accuracy | 10 µm |
| Linearity error | ± 4.5 % Mr (S = 0 ... 200 mm), ± 3.5 % Mr (S = 50 ... 150 mm) |
| Smallest object recognizable | 3 mm |
| Temperature drift | ± 0.03 % Sde/K |
| Light source | Pulsed infrared diode |
| Wave length | 850 nm |
| Response delay | < 1 ms |
| Measuring frequency | > 1100 Hz |
| Voltage supply range +Vs | 12 … 28 VDC |
| Current consumption max. (no load) | 100 mA |
| Output circuit | Analog and digital |
| Output signal | 4 ... 20 mA |
| Load resistance | < (+Vs - 9 V) / 0.02 A |
| Output current | <100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | IO-Link V1.1.3 |
| IO-Link port type | Class A |
| Baud rate | 230.4 kBaud (COM 3) |
| Cycle time | ≥ 1 ms |
| Process data length | 48 Bit |
| Process data structure | Smart Sensor Profile DMSS PDI48.MSDCF_1 |
| Width / diameter | 34.8 mm |
| Height / length | 71.2 mm |
| Depth | 16.8 mm |
| Design | Rectangular, front view |
| Housing material | Aluminum |
| Connection types | Connector M8 4 pin |
| Weight | 54 g |
| Ambient light immunity | < 60 kLux |
| Protection class | IP 67 |
| Operating temperature | 0 … +55 °C |
| Storage temperature | -20 … +60 °C |
IndMALL Automation Dealing offers Baumer Long Range Edge Sensor OE40.F22-YIN Article No: 11722385 at unbeatable prices. The Main Technical Parameters of OE40.F22-YIN, 11722385 feature LED green power-on indication and a LED yellow output indicator for clear, real-time system feedback. With a repeat accuracy of 10 µm and a temperature drift of only ± 0.03 % Sde/K, it ensures highly stable performance in varying industrial conditions. The voltage supply range is 12 … 28 VDC, and the device supports both Analog and digital output circuits, delivering a reliable 4 ... 20 mA output signal. Compact and lightweight, the unit has a depth of 16.8 mm and weighs only 54 g, making it ideal for space-constrained installations. It also offers excellent ambient light immunity, tolerating levels up to < 60 kLux. Designed for resilience, the storage temperature range spans from -20 … +60 °C. Take the First Step with a Quote for your requirement of Long Range Edge Sensor OE40.F22-YIN. Choose us for unparalleled pricing and support over other Dealers & Distributors.
