Baumer OADR 20I6475/S14F Ultrasonic Distance Sensor
The Baumer OADR 20I6475/S14F Laser Distance Sensor offers a Rectangular design, 50 β¦ 300 mm scanning range, Analog output, and Connector M12 8 pin connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OADR Series.
| Measuring distance Sd | 50 β¦ 300 mm |
| Output circuit | Analog |
Baumer OADR 20I6475/S14F Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Measuring distance Sd | 50 β¦ 300 mm |
| Adjustment | External |
| Power on indication | LED green |
| Linearity error | Β± 0.03 β¦ 1 mm |
| Beam type | Point |
| Temperature drift | < 0,03 % Sde/K |
| Light source | Pulsed red laser diode |
| Wave length | 650 nm |
| Voltage supply range +Vs | 12 β¦ 28 VDC |
| Current consumption max. (no load) | 100 mA |
| Output circuit | Analog |
| Width / diameter | 20.3 mm |
| Height / length | 65 mm |
| Depth | 51 mm |
| Design | Rectangular |
| Housing material | Stainless steel 1.4404 (V4A) |
| Front (optics) | PMMA |
| Connection types | Connector M12 8 pin |
| Ambient light immunity | < 8 kLux |
| Protection class | IP 69K & proTect+ |
| Operating temperature | 0 β¦ +50 Β°C |
| Output signal | 4 ... 20 mA / 0 ... 10 VDC |
| Output current | 100 mA |
Ask for the Pricing of Baumer Connector M12 8 pin Distance Sensor OADR 20I6475/S14F part no: 11017788 at unbeatable prices. Detailed Specifications of OADR 20I6475/S14F, 11017788 feature distance range of 100 β¦ 600 mm. This sensor utilizes External with a LED green power-on indicator. The Point type is point-based, using a Pulsed red laser diode at a wavelength of 650 nm. The sensor operates within a voltage supply range of 12 β¦ 28 VDC, with a maximum current consumption of 100 mA. The compact Rectangular design measures 20.3 mm in width, 65 mm in height, and 51 mm in depth, offering easy installation in tight spaces. Constructed with durable Stainless steel 1.4404 (V4A) housing, the front optics are made of PMMA for enhanced protection. The sensor connects via an Connector M12 8 pin making it ideal for industrial applications requiring high precision. Now's the Time to Secure a Quote for your requirement of Baumer Connector M12 8 pin Distance Sensor. We're committed to offering more favorable pricing and more responsive support than other Traders.
