Baumer OADM 21I6580/S14F Ultrasonic Distance Sensor
The Baumer OADM 21I6580/S14F Laser Distance Sensor offers a Rectangular design, 100 β¦ 600 mm scanning range, Analog output, and Connector M12 8 pin, rotatable connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OADM Series.
| Measuring distance Sd | 100 β¦ 600 mm |
| Output circuit | Analog |
Baumer OADM 21I6580/S14F Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Measuring distance Sd | 100 β¦ 600 mm |
| Adjustment | Teach-in: button / external |
| Power on indication | LED green |
| Linearity error | Β± 0.07 β¦ 1 mm |
| Beam type | Line |
| Temperature drift | < 0,012 % Sde/K |
| Light source | Pulsed red laser diode |
| Wave length | 650 nm |
| Voltage supply range +Vs | 12 β¦ 28 VDC |
| Current consumption max. (no load) | 100 mA |
| Output circuit | Analog |
| Width / diameter | 20.4 mm |
| Height / length | 135 mm |
| Depth | 45 mm |
| Design | Rectangular |
| Housing material | Aluminum |
| Front (optics) | Glass |
| Connection types | Connector M12 8 pin, rotatable |
| Ambient light immunity | < 10 kLux |
| Protection class | IP 67 |
| Operating temperature | 0 β¦ +50 Β°C |
| Output signal | 4 ... 20 mA / 0 ... 10 VDC |
| Output current | 100 mA |
Talk to Our Engineer for Baumer Laser Sensor For Displacement Accuracy OADM 21I6580/S14F part no: 10166224 with exclusive offers. Core System Specifications of OADM 21I6580/S14F, 10166224 are distance range of 200 β¦ 1000 mm. This sensor utilizes Teach-in: button / external with a LED green power-on indicator. The Line type is point-based, using a Pulsed red laser diode at a wavelength of 650 nm. The sensor operates within a voltage supply range of 12 β¦ 28 VDC, with a maximum current consumption of 100 mA. The compact Rectangular design measures 20.4 mm in width, 135 mm in height, and 45 mm in depth, offering easy installation in tight spaces. Constructed with durable Aluminum housing, the front optics are made of Glass for enhanced protection. The sensor connects via an Connector M12 8 pin, rotatable making it ideal for industrial applications requiring high precision. Don't Miss Out on a Quote for your requirement of Baumer Laser Sensor For Displacement Accuracy. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
