Baumer OADM 21I6480/S14F Ultrasonic Distance Sensor
The Baumer OADM 21I6480/S14F Laser Distance Sensor offers a Rectangular design, 100 β¦ 600 mm scanning range, Analog output, and Connector M12 8 pin, rotatable connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OADM Series.
| Measuring distance Sd | 100 β¦ 600 mm |
| Output circuit | Analog |
Baumer OADM 21I6480/S14F Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Measuring distance Sd | 100 β¦ 600 mm |
| Adjustment | Teach-in: button / external |
| Power on indication | LED green |
| Linearity error | Β± 0.07 β¦ 1 mm |
| Beam type | Point |
| Temperature drift | < 0,012 % Sde/K |
| Light source | Pulsed red laser diode |
| Wave length | 650 nm |
| Voltage supply range +Vs | 12 β¦ 28 VDC |
| Current consumption max. (no load) | 100 mA |
| Output circuit | Analog |
| Width / diameter | 20.4 mm |
| Height / length | 135 mm |
| Depth | 45 mm |
| Design | Rectangular |
| Housing material | Aluminum |
| Front (optics) | Glass |
| Connection types | Connector M12 8 pin, rotatable |
| Ambient light immunity | < 10 kLux |
| Protection class | IP 67 |
| Operating temperature | 0 β¦ +50 Β°C |
| Output signal | 4 ... 20 mA / 0 ... 10 VDC |
| Output current | 100 mA |
Mail Us for your needs in Baumer Rotatable Laser Sensor OADM 21I6480/S14F part no: 10165289 with budget-friendly prices. The Main Technical Parameters of OADM 21I6480/S14F, 10165289 inludce distance range of 200 β¦ 1000 mm. This sensor utilizes Teach-in: button / external with a LED green power-on indicator. The Point type is point-based, using a Pulsed red laser diode at a wavelength of 650 nm. The sensor operates within a voltage supply range of 12 β¦ 28 VDC, with a maximum current consumption of 100 mA. The compact Rectangular design measures 20.4 mm in width, 135 mm in height, and 45 mm in depth, offering easy installation in tight spaces. Constructed with durable Aluminum housing, the front optics are made of Glass for enhanced protection. The sensor connects via an Connector M12 8 pin, rotatable making it ideal for industrial applications requiring high precision. Customize Your Experience with a Quote for your requirement of Baumer Rotatable Laser Sensor. Experience the difference with our competitive pricing and superior support over other Suppliers.
