Baumer OADM 20I6580/S14F Ultrasonic Distance Sensor
The Baumer OADM 20I6580/S14F Laser Distance Sensor offers a Rectangular design, 100 β¦ 600 mm scanning range, Analog output, and Connector M12 8 pin, rotatable connection. Manufactured by Baumer under the Baumer Laser Distance Sensor category, this model belongs to the OADM Series.
| Measuring distance Sd | 100 β¦ 600 mm |
| Output circuit | Analog |
Baumer OADM 20I6580/S14F Ultrasonic Distance Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Measuring distance Sd | 100 β¦ 600 mm |
| Adjustment | Teach-in: button / external |
| Power on indication | LED green |
| Linearity error | Β± 0.05 β¦ 2 mm |
| Beam type | Line |
| Temperature drift | < 0,03 % Sde/K |
| Light source | Pulsed red laser diode |
| Wave length | 650 nm |
| Voltage supply range +Vs | 12 β¦ 28 VDC |
| Current consumption max. (no load) | 100 mA |
| Output circuit | Analog |
| Width / diameter | 20.6 mm |
| Height / length | 65 mm |
| Depth | 50 mm |
| Design | Rectangular |
| Housing material | Die-cast zinc |
| Front (optics) | Glass |
| Connection types | Connector M12 8 pin, rotatable |
| Ambient light immunity | < 10 kLux |
| Protection class | IP 67 |
| Operating temperature | 0 β¦ +50 Β°C |
| Output signal | 4 ... 20 mA / 0 ... 10 VDC |
| Output current | 100 mA |
Get A Quote for Baumer 600 mm Measuring Distance Sensor OADM 20I6580/S14F part no: 10144077 at the best price. Here are the brief Technical Specifications of OADM 20I6580/S14F, 10144077 are distance range of 200 β¦ 1000 mm. This sensor utilizes Teach-in: button / external with a LED green power-on indicator. The Line type is point-based, using a Pulsed red laser diode at a wavelength of 650 nm. The sensor operates within a voltage supply range of 12 β¦ 28 VDC, with a maximum current consumption of 100 mA. The compact Rectangular design measures 20.6 mm in width, 65 mm in height, and 50 mm in depth, offering easy installation in tight spaces. Constructed with durable Die-cast zinc housing, the front optics are made of Glass for enhanced protection. The sensor connects via an Connector M12 8 pin, rotatable making it ideal for industrial applications requiring high precision. It's Time to get a Quote for your requirement of Baumer 600 mm Measuring Distance Sensor. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
