Baumer O500W.ER-GW1B.PVO Photoelectric Sensor
The Baumer O500W.ER-GW1B.PVO Photoelectric Sensor offers a Rectangular design, 40 m nominal range, Receiver, Push-pull output, and Connector M12 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O500W.ER-GW1B.PVO |
Baumer O500W.ER-GW1B.PVO Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 25 m |
| Nominal range Sn | 40 m |
| Alignment / soiled lens indicator | Flashing light indicator |
| Power on indication | LED green |
| Sensitivity adjustment | qTeach / remote |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <3 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 20.2 mm |
| Height / length | 47.2 mm |
| Depth | 37.7 mm |
| Design | Rectangular |
| Housing material | Stainless steel 1.4404 (V4A) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 68/69K & proTect+ |
| Light indicator | LED yellow |
Call us for Baumer Through Beam Optical Sensor Design O500W.ER-GW1B.PVO part no: 11167303 at the best rates. Technical Attributes of O500W.ER-GW1B.PVO, 11167303 are Through beam sensor Model Type designed for precise object detection with a nominal range of 40 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 40 mA and a typical consumption of 30 mA. The compact Rectangular design features dimensions of 20.2 mm in width, 47.2 mm in height, and 37.7 mm in depth, ensuring easy installation in various industrial environments. The housing is made from durable Stainless steel 1.4404 (V4A) offering robustness for demanding applications. The sensor connects via a Connector M12 4 pin making it suitable for seamless integration into your system. With a Receiver. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Through Beam Optical Sensor Design. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
