Baumer O500H.TR-ZZZZ.PVOK Photoelectric Sensor
The Baumer O500H.TR-ZZZZ.PVOK Photoelectric Sensor offers a Rectangular design, 40 m nominal range, Emitter, output, and Flylead connector M12, L=200 mm connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O500H.TR-ZZZZ.PVOK |
Baumer O500H.TR-ZZZZ.PVOK Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Emitter |
| Actual range Sb | 25 m |
| Nominal range Sn | 40 m |
| Power on indication | LED green |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Reverse polarity protection | Yes |
| Width / diameter | 20.2 mm |
| Height / length | 47.7 mm |
| Depth | 36.4 mm |
| Design | Rectangular |
| Housing material | Stainless steel 1.4404 (V4A) |
| Front (optics) | PMMA |
| Connection types | Flylead connector M12, L=200 mm |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 68/69K & proTect+ |
| Light source | Pulsed red LED |
| Wave length | 645 nm |
Ask for the Pricing of Baumer Flylead Connector M12 Beam Sensor O500H.TR-ZZZZ.PVOK part no: 11167296 at unbeatable prices. Detailed Specifications of O500H.TR-ZZZZ.PVOK, 11167296 feature Through beam sensor Model Type designed for precise object detection with a nominal range of 40 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 40 mA and a typical consumption of 30 mA. The compact Rectangular design features dimensions of 20.2 mm in width, 47.7 mm in height, and 36.4 mm in depth, ensuring easy installation in various industrial environments. The housing is made from durable Stainless steel 1.4404 (V4A) offering robustness for demanding applications. The sensor connects via a Flylead connector M12, L=200 mm making it suitable for seamless integration into your system. With a Emitter. Now's the Time to Secure a Quote for your requirement of Baumer Flylead Connector M12 Beam Sensor. We're committed to offering more favorable pricing and more responsive support than other Traders.
