Before procurement teams confirm O500-RR-GD1Z-72O, they typically review Sick Diffuse Sensor, Baumer Proximity Sensor and Baumer O200 Tr Zzzx 72Nv H006 to double-check performance ratings, stock availability, and supplier credibility carefully.
Baumer O500.RR-GD1Z.72O Photoelectric Sensor
The Baumer O500.RR-GD1Z.72O Photoelectric Sensor offers a Rectangular design, 8 m nominal range, 10 โฆ 30 VDC supply voltage, Push-pull output, and Connector M12 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | O500.RR-GD1Z.72O |
Baumer O500.RR-GD1Z.72O Photoelectric Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed red LED |
| Actual range Sb | 7.5 m |
| Nominal range Sn | 8 m |
| Polarization filter | Yes |
| Power on indication | LED green |
| Sensitivity adjustment | No |
| Wave length | 630 nm |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 1ยฐ |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 โฆ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <3 VDC |
| Output function | Dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Width / diameter | 18 mm |
| Height / length | 45 mm |
| Depth | 32 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Operating temperature | -25 โฆ +60 ยฐC |
| Protection class | IP 67 |
Reach Us by Email for Baumer Industrial Photoelectric Sensor For Alignment O500.RR-GD1Z.72O part no: 11096091 at Discounted Rates. Key Technical Features of O500.RR-GD1Z.72O, 11096091 are Retro-reflective sensor designed for precision detection with an actual range of 7.5 m and a nominal range of 8 m. The sensor features a Pulsed red LED light source with a wavelength of 630 nm, ensuring accurate performance with a response time of less than < 0.49 ms. It operates within a voltage supply range of 10 โฆ 30 VDC, supporting both Dark operate functions through a Push-pull output circuit capable of handling up to 100 mA of output current. Measuring 18 mm in width and 45 mm in height, the sensorโs compact Rectangular design is housed in durable Plastic (ASA, PMMA) materials, making it ideal for industrial environments. The sensor connects via a Connector M12 4 pin for reliable integration. Navigate Your Needs with a Quote for your requirement of Baumer Industrial Photoelectric Sensor For Alignment. Our pricing and support are unrivaled, especially when compared to other Competitors.
