Baumer O500.DP-GM1J.72CU Photoelectric Sensor
The Baumer O500.DP-GM1J.72CU Photoelectric Sensor offers a Rectangular design, 60 β¦ 400 mm measuring distance, 10 β¦ 30 VDC supply voltage, Push-pull output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O300/O500 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O500.DP-GM1J.72CU |
Baumer O500.DP-GM1J.72CU Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Distance measuring |
| Version | IO-Link measuring |
| Measuring distance Sd | 60 β¦ 400 mm |
| Adjustment | Teach-in and IO-Link |
| Power on indication | LED green |
| Light indicator | LED yellow |
| Resolution | 500 β¦ 3000 Β΅m |
| Linearity error | Β± 3 β¦ 20 mm |
| Beam type | Point |
| Alignment optical axis | < 1Β° |
| Temperature drift | < 0,2 % Sde/K |
| Light source | Pulsed PinPoint LED |
| Wave length | 630 nm |
| Response time / release time | < 0.49 ms |
| Current consumption max. (no load) | 40 mA |
| Voltage drop Vd | <3 VDC |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | IO-Link V1.1 |
| Baud rate | 38.4 kBaud (COM 2) |
| Cycle time | β₯ 2.7 ms |
| Process data length | 3 Byte |
| Width / diameter | 18 mm |
| Height / length | 45 mm |
| Depth | 32 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Protection class | IP 67 |
| Operating temperature | -25 β¦ +60 Β°C |
Call us for Baumer Distance Sensor With Push-Pull Output O500.DP-GM1J.72CU part no: 11199082 at the best rates. Technical Attributes of O500.DP-GM1J.72CU, 11199082 are Distance measuring Sensor with IO-Link measuring capabilities, designed for accurate detection with a measuring distance of 60 β¦ 400 mm. The sensor allows easy adjustment through Teach-in and IO-Link, featuring a LED green power-on indication for operational clarity. It utilizes a Pulsed PinPoint LED with a wavelength of 630 nm and a response time of less than < 0.49 ms. Operating within a voltage supply range of 10 β¦ 30 VDC, the sensor has a maximum current consumption of 40 mA when idle. The Push-pull output circuit ensures flexibility in integration. Measuring 18 mm in width, 45 mm in height, and 32 mm in depth, the compact Rectangular design makes it easy to install. It comes equipped with a durable Cable 4 pin, 2 m for secure connections. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Distance Sensor With Push-Pull Output. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
