Baumer O330.RP-NDNVZ.72N Photoelectric Sensor
The Baumer O330.RP-NDNVZ.72N Photoelectric Sensor offers a Rectangular design, 6 m nominal range, 10 โฆ 30 VDC supply voltage, NPN complementary output, and Connector M8 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | O330.RP-NDNVZ.72N |
Baumer O330.RP-NDNVZ.72N Photoelectric Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed PinPoint LED |
| Actual range Sb | 5 m |
| Nominal range Sn | 6 m |
| Polarization filter | Yes |
| Alignment / soiled lens indicator | Flashing output indicator |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Wave length | 634 nm |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 1,5ยฐ |
| Response time / release time | < 0.5 ms |
| Voltage supply range +Vs | 10 โฆ 30 VDC |
| Current consumption max. (no load) | 50 mA |
| Current consumption typ. | 25 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN complementary |
| Output current | 100 mA |
| Width / diameter | 11 mm |
| Height / length | 32 mm |
| Depth | 21 mm |
| Design | Rectangular |
| Mechanical mounting | Sleeve smooth (brass) |
| Housing material | Plastic (ABS, ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Operating temperature | -25 โฆ +55 ยฐC |
| Protection class | IP 67 |
Ask for the Pricing of Baumer Photoelectric Sensor With M8 4-Pin Connector O330.RP-NDNVZ.72N part no: 11261063 at unbeatable prices. Detailed Specifications of O330.RP-NDNVZ.72N, 11261063 feature Retro-reflective sensor designed for precision detection with an actual range of 5 m and a nominal range of 6 m. The sensor features a Pulsed PinPoint LED light source with a wavelength of 634 nm, ensuring accurate performance with a response time of less than < 0.5 ms. It operates within a voltage supply range of 10 โฆ 30 VDC, supporting both Light / dark operate functions through a NPN complementary output circuit capable of handling up to 100 mA of output current. Measuring 11 mm in width and 32 mm in height, the sensorโs compact Rectangular design is housed in durable Plastic (ABS, ASA, PMMA) materials, making it ideal for industrial environments. The sensor connects via a Connector M8 4 pin for reliable integration. Now's the Time to Secure a Quote for your requirement of Baumer Photoelectric Sensor With M8 4-Pin Connector. We're committed to offering more favorable pricing and more responsive support than other Traders.
