Baumer O330.GP-GLZZB.72ZV/E022 Photoelectric Sensor
The Baumer O330.GP-GLZZB.72ZV/E022 Photoelectric Sensor offers a Rectangular design, 20 β¦ 250 mm sensing distance, Push-pull output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the Background Suppression type.
| Sensing distance Tw | 20 β¦ 250 mm |
| Sensing range Tb | 8 β¦ 275 mm |
| Output circuit | Push-pull |
| Connection types | Cable 4 pin, 2 m |
Baumer O330.GP-GLZZB.72ZV/E022 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Background suppression |
| Sensing distance Tw | 20 β¦ 250 mm |
| Sensing range Tb | 8 β¦ 275 mm |
| Power on indication | LED green |
| Output indicator | LED yellow |
| Sensing distance adjustment | qTeach / external |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 1,5Β° |
| Light source | Pulsed PinPoint LED |
| Wave length | 634 nm |
| Response time / release time | < 2.5 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 50 mA |
| Current consumption typ. | 25 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Width / diameter | 11 mm |
| Height / length | 32 mm |
| Depth | 21 mm |
| Design | Rectangular |
| Mechanical mounting | Sleeve smooth (brass) |
| Housing material | Plastic (ABS, ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Cable characteristics | PVC / PVC 4 x 0.14 mmΒ² |
| Protection class | IP 67 |
| Operating temperature | -25 β¦ +55 Β°C |
Send Your Inquiry for Baumer Photoelectric Sensor For Automation Machines O330.GP-GLZZB.72ZV/E022 part no: 11261222 with cost-effective solutions. Essential Technical Specs of O330.GP-GLZZB.72ZV/E022, 11261222 are Background suppression Sensor, engineered for precise detection with a sensing distance (Tw) of 20 β¦ 250 mm. The sensor features qTeach / external adjustment for flexible setup and utilizes an Pulsed PinPoint LED light source with a wavelength of 634 nm. It boasts a fast response time of less than < 2.5 ms, and operates within a voltage supply range of 10 β¦ 30 VDC, with a typical current consumption of 25 mA. The output function supports Light / dark operate with a Push-pull output circuit and can handle an output current of up to 100 mA. Measuring 11 mm in width, 32 mm in height, and 21 mm in depth, this compact Rectangular sensor is connected via a Cable 4 pin, 2 m. Capture the Best Deal with a Quote for your requirement of Baumer Photoelectric Sensor For Automation Machines. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
