Baumer O330.EP-NDNVZ.72ZV Photoelectric Sensor
The Baumer O330.EP-NDNVZ.72ZV Photoelectric Sensor offers a Rectangular design, 12 m nominal range, Receiver, NPN complementary output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O330.EP-NDNVZ.72ZV |
Baumer O330.EP-NDNVZ.72ZV Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 10 m |
| Nominal range Sn | 12 m |
| Alignment / soiled lens indicator | Flashing output indicator |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Sensitivity adjustment | No |
| Suppression of reciprocal influence | Yes |
| Response time / release time | < 0.8 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 50 mA |
| Current consumption typ. | 25 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN complementary |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 11 mm |
| Height / length | 32 mm |
| Depth | 21 mm |
| Design | Rectangular |
| Mechanical mounting | Sleeve smooth (brass) |
| Housing material | Plastic (ABS, ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Cable characteristics | PVC / PVC 4 x 0.14 mmΒ² |
| Operating temperature | -25 β¦ +55 Β°C |
| Protection class | IP 67 |
Obtain a Quote for Baumer Light/Dark Operate Sensor O330.EP-NDNVZ.72ZV part no: 11261245 at economical prices. Specifications Overview for O330.EP-NDNVZ.72ZV, 11261245 reveals Through beam sensor Model Type designed for precise object detection with a nominal range of 12 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 50 mA and a typical consumption of 25 mA. The compact Rectangular design features dimensions of 11 mm in width, 32 mm in height, and 21 mm in depth, ensuring easy installation in various industrial environments. The housing is made from durable Plastic (ABS, ASA, PMMA) offering robustness for demanding applications. The sensor connects via a Cable 4 pin, 2 m making it suitable for seamless integration into your system. With a Receiver. Take the First Step with a Quote for your requirement of Baumer Light/Dark Operate Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
