Baumer O300W.RL-GW1J.PVN Photoelectric Sensor
The Baumer O300W.RL-GW1J.PVN Photoelectric Sensor offers a Rectangular design, 6 m nominal range, 11 โฆ 30 VDC supply voltage, Push-pull output, and Connector M8 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | O300W.RL-GW1J.PVN |
Baumer O300W.RL-GW1J.PVN Photoelectric Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed red laser diode |
| Actual range Sb | 5 m |
| Nominal range Sn | 6 m |
| Polarization filter | Yes |
| Power on indication | LED green |
| Sensitivity adjustment | Teach-in and IO-Link |
| Wave length | 656 nm |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 2ยฐ |
| Response time / release time | < 0.1 ms |
| Voltage supply range +Vs | 11 โฆ 30 VDC |
| Current consumption max. (no load) | 30 mA |
| Current consumption typ. | 25 mA |
| Voltage drop Vd | <2.5 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Width / diameter | 16.5 mm |
| Height / length | 34.7 mm |
| Depth | 28.2 mm |
| Design | Rectangular |
| Housing material | Stainless steel 1.4404 (V4A) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Operating temperature | -10 โฆ +60 ยฐC |
| Protection class | IP 68/69K & proTect+ |
Obtain a Quote for Baumer Sensor With 11-30VDC Supply Voltage Range O300W.RL-GW1J.PVN part no: 11172815 at economical prices. Specifications Overview for O300W.RL-GW1J.PVN, 11172815 reveals Retro-reflective sensor designed for precision detection with an actual range of 5 m and a nominal range of 6 m. The sensor features a Pulsed red laser diode light source with a wavelength of 656 nm, ensuring accurate performance with a response time of less than < 0.1 ms. It operates within a voltage supply range of 11 โฆ 30 VDC, supporting both Light / dark operate functions through a Push-pull output circuit capable of handling up to 100 mA of output current. Measuring 16.5 mm in width and 34.7 mm in height, the sensorโs compact Rectangular design is housed in durable Stainless steel 1.4404 (V4A) materials, making it ideal for industrial environments. The sensor connects via a Connector M8 4 pin for reliable integration. Take the First Step with a Quote for your requirement of Baumer Sensor With 11-30VDC Supply Voltage Range. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
