Baumer O300H.RP-GW1B.PVCV Photoelectric Sensor
The Baumer O300H.RP-GW1B.PVCV Photoelectric Sensor offers a Rectangular design, 6 m nominal range, 10 β¦ 30 VDC supply voltage, Push-pull output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | O300H.RP-GW1B.PVCV |
Baumer O300H.RP-GW1B.PVCV Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed PinPoint LED |
| Actual range Sb | 5 m |
| Nominal range Sn | 6 m |
| Polarization filter | Yes |
| Power on indication | LED green |
| Sensitivity adjustment | Teach-in: remote |
| Wave length | 630 nm |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 2Β° |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 35 mA |
| Current consumption typ. | 25 mA |
| Voltage drop Vd | <3 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Width / diameter | 16.5 mm |
| Height / length | 34.6 mm |
| Depth | 28.7 mm |
| Design | Rectangular |
| Housing material | Stainless steel 1.4404 (V4A) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 68/69K & proTect+ |
Get A Quote for Baumer Retro-Reflective Sensor With 630 nm Wave Length O300H.RP-GW1B.PVCV part no: 11127716 at the best price. Here are the brief Technical Specifications of O300H.RP-GW1B.PVCV, 11127716 are Retro-reflective sensor designed for precision detection with an actual range of 5 m and a nominal range of 6 m. The sensor features a Pulsed PinPoint LED light source with a wavelength of 630 nm, ensuring accurate performance with a response time of less than < 0.49 ms. It operates within a voltage supply range of 10 β¦ 30 VDC, supporting both Light / dark operate functions through a Push-pull output circuit capable of handling up to 100 mA of output current. Measuring 16.5 mm in width and 34.6 mm in height, the sensorβs compact Rectangular design is housed in durable Stainless steel 1.4404 (V4A) materials, making it ideal for industrial environments. The sensor connects via a Cable 4 pin, 2 m for reliable integration. It's Time to get a Quote for your requirement of Baumer Retro-Reflective Sensor With 630 nm Wave Length. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
