Baumer O300.TR-ZZZZ.72CU Photoelectric Sensor
The Baumer O300.TR-ZZZZ.72CU Photoelectric Sensor offers a Rectangular design, 15 m nominal range, Emitter, output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O300.TR-ZZZZ.72CU |
Baumer O300.TR-ZZZZ.72CU Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Emitter |
| Actual range Sb | 10 m |
| Nominal range Sn | 15 m |
| Power on indication | LED green |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Reverse polarity protection | Yes |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 67 |
| Light source | Pulsed red LED |
| Wave length | 645 nm |
Call us for Baumer Optical Sensor With Through Beam O300.TR-ZZZZ.72CU part no: 11167264 at the best rates. Technical Attributes of O300.TR-ZZZZ.72CU, 11167264 are Through beam sensor Model Type designed for precise object detection with a nominal range of 15 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 40 mA and a typical consumption of 30 mA. The compact Rectangular design features dimensions of 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, ensuring easy installation in various industrial environments. The housing is made from durable Plastic (ASA, PMMA) offering robustness for demanding applications. The sensor connects via a Cable 4 pin, 2 m making it suitable for seamless integration into your system. With a Emitter. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Optical Sensor With Through Beam. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
