Baumer O300.TI-ZZZZ.72N Photoelectric Sensor
The Baumer O300.TI-ZZZZ.72N Photoelectric Sensor offers a Rectangular design, 15 m nominal range, Emitter, output, and Connector M8 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O300.TI-ZZZZ.72N |
Baumer O300.TI-ZZZZ.72N Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Emitter |
| Actual range Sb | 10 m |
| Nominal range Sn | 15 m |
| Power on indication | LED green |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Reverse polarity protection | Yes |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 67 |
| Light source | Pulsed infrared diode |
| Wave length | 850 nm |
Talk to Our Engineer for Baumer Emitter Through-beam Sensor O300.TI-ZZZZ.72N part no: 11209573 with exclusive offers. Core System Specifications of O300.TI-ZZZZ.72N, 11209573 are Through beam sensor Model Type designed for precise object detection with a nominal range of 15 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 40 mA and a typical consumption of 30 mA. The compact Rectangular design features dimensions of 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, ensuring easy installation in various industrial environments. The housing is made from durable Plastic (ASA, PMMA) offering robustness for demanding applications. The sensor connects via a Connector M8 4 pin making it suitable for seamless integration into your system. With a Emitter. Don't Miss Out on a Quote for your requirement of Baumer Emitter Through-beam Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
