During technical comparisons, O300-RP-T-GW1J-72N appears alongside Sick Diffuse Sensor, Baumer Proximity Sensor and Baumer O200 Tr Zzzx 72Nv H006 so engineers assess signal types, ingress protection, and ambient tolerances accurately.
Baumer O300.RP.T-GW1J.72N Photoelectric Sensor
The Baumer O300.RP.T-GW1J.72N Photoelectric Sensor offers a Rectangular design, 4 m nominal range, 10 β¦ 30 VDC supply voltage, Push-pull output, and Connector M8 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | O300.RP.T-GW1J.72N |
Baumer O300.RP.T-GW1J.72N Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed PinPoint LED |
| Actual range Sb | 3.5 m |
| Nominal range Sn | 4 m |
| Polarization filter | Yes |
| Power on indication | LED green |
| Sensitivity adjustment | Teach-in and IO-Link |
| Wave length | 630 nm |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 2Β° |
| Response time / release time | < 0.25 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 35 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <3 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 67 |
Mail Us for your needs in Baumer Photoelectric Sensor For Reflective Detection O300.RP.T-GW1J.72N part no: 11157334 with budget-friendly prices. The Main Technical Parameters of O300.RP.T-GW1J.72N, 11157334 inludce Retro-reflective sensor designed for precision detection with an actual range of 3.5 m and a nominal range of 4 m. The sensor features a Pulsed PinPoint LED light source with a wavelength of 630 nm, ensuring accurate performance with a response time of less than < 0.25 ms. It operates within a voltage supply range of 10 β¦ 30 VDC, supporting both Light / dark operate functions through a Push-pull output circuit capable of handling up to 100 mA of output current. Measuring 12.9 mm in width and 32.3 mm in height, the sensorβs compact Rectangular design is housed in durable Plastic (ASA, PMMA) materials, making it ideal for industrial environments. The sensor connects via a Connector M8 4 pin for reliable integration. Customize Your Experience with a Quote for your requirement of Baumer Photoelectric Sensor For Reflective Detection. Experience the difference with our competitive pricing and superior support over other Suppliers.
