Baumer O300.GR-GW1T.72CU Photoelectric Sensor
The Baumer O300.GR-GW1T.72CU Photoelectric Sensor offers a Rectangular design, 30 β¦ 300 mm sensing distance, Push-pull output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the Background Suppression type.
| Sensing distance Tw | 30 β¦ 300 mm |
| Sensing range Tb | 15 β¦ 300 mm |
| Output circuit | Push-pull |
| Connection types | Cable 4 pin, 2 m |
Baumer O300.GR-GW1T.72CU Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Background suppression |
| Sensing distance Tw | 30 β¦ 300 mm |
| Sensing range Tb | 15 β¦ 300 mm |
| Power on indication | LED green |
| Sensing distance adjustment | qTeach |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 2Β° |
| Light source | Pulsed red LED |
| Wave length | 630 nm |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 45 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <3 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Protection class | IP 67 |
| Operating temperature | -25 β¦ +60 Β°C |
| Light indicator | LED yellow |
Obtain a Quote for Baumer Sensor With High Precision Sensing O300.GR-GW1T.72CU part no: 11120106 at economical prices. Specifications Overview for O300.GR-GW1T.72CU, 11120106 reveals Background suppression Sensor, engineered for precise detection with a sensing distance (Tw) of 30 β¦ 300 mm. The sensor features qTeach adjustment for flexible setup and utilizes an Pulsed red LED light source with a wavelength of 630 nm. It boasts a fast response time of less than < 1 ms, and operates within a voltage supply range of 10 β¦ 30 VDC, with a typical current consumption of 30 mA. The output function supports Light / dark operate with a Push-pull output circuit and can handle an output current of up to 100 mA. Measuring 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, this compact Rectangular sensor is connected via a Cable 4 pin, 2 m. Take the First Step with a Quote for your requirement of Baumer Sensor With High Precision Sensing. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
