Baumer O300.EL-GW1B.72CU Photoelectric Sensor
The Baumer O300.EL-GW1B.72CU Photoelectric Sensor offers a Rectangular design, 75 m nominal range, Receiver, Push-pull output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | O300.EL-GW1B.72CU |
Baumer O300.EL-GW1B.72CU Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 40 m |
| Nominal range Sn | 75 m |
| Alignment / soiled lens indicator | Flashing light indicator |
| Power on indication | LED green |
| Sensitivity adjustment | qTeach / remote |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <3 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 β¦ +60 Β°C |
| Protection class | IP 67 |
| Light indicator | LED yellow |
Obtain a Quote for Baumer Light/Dark Operation Beam Sensor O300.EL-GW1B.72CU part no: 11176842 at economical prices. Specifications Overview for O300.EL-GW1B.72CU, 11176842 reveals Through beam sensor Model Type designed for precise object detection with a nominal range of 75 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 40 mA and a typical consumption of 30 mA. The compact Rectangular design features dimensions of 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, ensuring easy installation in various industrial environments. The housing is made from durable Plastic (ASA, PMMA) offering robustness for demanding applications. The sensor connects via a Cable 4 pin, 2 m making it suitable for seamless integration into your system. With a Receiver. Take the First Step with a Quote for your requirement of Baumer Light/Dark Operation Beam Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
